Canon Image Reader-A1 iR5000i Service Manual page 564

CHAPTER 9 SHIFT TRAY
1)
2) The grounding wire terminal of the limit sensor (front, rear) must be
9-8 P
When adjusting the position of the limit senor (front, rear), be sure to
start at the point farthest from the paper, moving closer to the sensor.
level in relation to the sensor as shown; in addition, make sure that the
bend of the terminal must face downward.
Grounding wire terminal
COPYRIGHT © 2001 CANON INC.
F09-501-02
2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
