5.1.1 Pickup assembly
Pickup assembly
1) Is the print paper curled or wavy?
YES: Replace the paper. Advise the user on the correct method of storing
2) Try paper of a recommended type. Is the problem corrected?
YES: Advise the user to use recommended paper.
DC controller PCB, Pickup clutch
3) Are the pickup roller of the selected cassette or the deck and the
NO:
Pickup roller
4) Is the pickup roller deformed or worn?
YES: Replace the pickup roller.
Guide plate
NO:
5.1.2 Separation/Feeding assembly
Print paper
1) Is the leading edge of print paper past the registration roller?
YES: Go to step 5.
NO:
Registration roller
2) Is the coupling of the registration roller engaged correctly?
NO:
3) Is the registration roller deformed (worn) or soiled?
YES: If dirt is found, clean it with alcohol; if deformation (i.e., wear) is
4) Are the retaining springs on both ends of the registration roller
NO:
YES: Check the transfer guide for foreign matte and deformation.
Registration clutch
5) Is the operation of the registration clutch normal?
NO:
COPYRIGHT © 2001 CANON INC.
CHAPTER 4 TROUBLESHOOTING IMAGE FAULTS/MALFUNCTIONS
paper.
DC controller PCB, Pickup clutch
feeding roller of the manual feed tray rotating during printing?
See "Pickup fails" for each source of paper.
Check the guide plate for deformation.
Check the distance between the upper and lower guides in front of
the registration roller; then, make adjustments as needed.
Mount the fixing/feeding unit correctly.
found, replace it.
mounted correctly?
Mount them correctly.
Check the registration clutch.
