CHAPTER 3 STANDARDS AND ADJUSTMENTS

3. Image Formation System

3.1 Routing the Grid Wire of the Primary Charging Assembly

See the Printer Manual: Chap. 4>7.8 "Charging Wire"

3.2 Routing the Charging Wire of Charging Assemblies

See the Printer Unit: Chap. 4>7.8 "Charging Wire"

3.3 Mounting the Drum Cleaning Blade

See the Printer Manual: Chap. 4>7.11 "Drum Cleaner"

3.4 Mounting the Developing Blade

See the Printer Manual: Chap. 4>7.9 "Developing Assembly"

3.5 Replacing the Potential Sensor/Potential Control PCB

See the Printer Unit: Chap. 4>7.4 "Potential Sensor Assembly"
1. The potential sensor and the potential control PCB are adjusted as a
2. If you have replaced the sensor and the PCB, be sure to execute offset
3-8 T
single unit; be sure to replace both at the same time.
adjustment of the sensor.
