5.2 When Replacing the CCD/AP PCB

Be sure to execute 'CCD auto adjustment' in service mode, and record the updated CCD
adjustment data on the service label.
1. CCD Auto Adjustment
COPIER>FUNCTION>CCD
>CCD-ADJ
2. CCD Adjustment data
all items under
COPIER>ADJUST>CCD
