Canon Image Reader-A1 iR5000i Service Manual page 868

CHAPTER 5 SERVICE MODE
<Guide to Consumables Counter>
The machine is equipped with consumables counters (PRDC-1, DRBL-1, DRBL-2), pro-
viding references for parts replaced on a periodical basis or parts requiring replacement.
EX.
PRM-WIRE / 00000027 /
[1]
[1] Indicates the name of the part. In the case of the example, the primary charging wire.
[2] Indicates the counter reading (number of actual sheets handled); clear it by pressing the
Clear key after replacing the part.
[3] Indicates the limit setting (guide to replacement); the setting may be changed by select-
ing the image and using the keypad (thereafter, press the OK key).
[4] Indicates the ratio of counter readings to limit levels.
[5] A single exclamation mark (!) will be indicated between 90% and 100%; two marks at
100% or higher; otherwise, no mark.
[6] Indicates an estimated number of days to replacement; in the case of the example, 82
days.
Level 1: COUNTER
Level 2: TOTAL
Level 3: SERVICE 1
SERVICE 2
COPY
PDL-PRT
FAX-PRT
PMT-PRT
BOX-PRT
RPT-PRT
2-SIDE
SCAN
5-102 T
00500000 /
[2] [3]
List of Counter Items
Mode
total counter 1 for servicing
total counter 2 for servicing
copy counter
PDL print counter
fax reception print counter
remote copy/print counter
Box print counter
report print counter
double-sided print counter
scanner counter
COPYRIGHT © 2001 CANON INC.
0% !! 000082
[4] [5] [6]
2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
COPIER>COUNTER
