3.5.2 Saddle Stitcher Unit

Address Bit Notation
IO-P023 0 M6S
(output) 1 M6S
2 M7S
3 M7S
4 M2S
5 M2S
6 SL1S
7 SL2S
8
IO-P024 0
(output) 1
2
3
4
5 SL4S
6
7 M4S
8
IO-P025 0
(input) 1 PI15S
2 PI11S
3
4
5
6
7
8
IO-P026 0
(input) 1
2 PI14S
3 PI5S
4
5
6
7
8
COPYRIGHT © 2001 CANON INC.
Description
stitcher motor (rear) CW drive output
stitcher motor (rear) CCW drive output
stitcher motor (front) CW drive output
stitcher motor (front) CCW drive output
paper fold motor CW drive output
paper fold motor CCW drive output
No. 1 deflecting plate solenoid drive signal
No. 2 deflecting plate solenoid drive signal
not used
not used
not used
not used
not used
not used
feed roller plate solenoid drive signal
solenoid timer output
paper positioning plate motor current switch
not used
24-V output OFF detection signal
paper push-on plate leading edge position signal
delivery detection signal
not used
not used
not used
not used
not used
not used
paper fold motor clock detection signal
paper push-on plate motor clock detection signal
paper push-on HP detection signal
alignment plate HP detection signal
not used
not used
not used
not used
not used
2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
CHAPTER 5 SERVICE MODE
Remarks
0: CW
0: CCW
0: CW
0: CCW
0: CW
0: CCW
1: ON
1: ON
1: ON
0: when ON
1: down
0: leading edge
0: paper present
1: HP
0: HP
5-41 T
