CHAPTER 8 PAPER DECK
The DC controller of the host machine identifies a jam under the following conditions:
1. When the host machine is turned on, or at the end of wait-up or in standby, paper exits
over the deck feed sensor (PS106).
• Deck Pickup/Vertical Path Delay Jam
Deck pickup clutch
(CL102)
Jam check
Deck pickup sensor
(PS101)
Deck feed sensor
(PS106)
Deck main motor
(M101)
8-18 P
Start key
ON
INTR
Normal
F08-201-02
COPYRIGHT © 2001 CANON INC.
Jam indicator ON
SCAN
2000 2000 2000 2000
PRINT
Error
