CHAPTER 5 PICK UP/FEEDING SYSTEM
3) Detach the separation roller [7] from the
separation roller shaft support.
The urethane sponge used in the
part is pink at the beginning,
and changes to yellow over time
(accelerated if exposed to light;
it may appear to change to or-
ange before turning pink). This
is a common characteristic of
urethane sponge, and does not
indicate physical deterioration
(performance). In addition, note
that the part is not classified by
color.
5-58 P
COPYRIGHT © 2001 CANON INC.
Cassette 3/4
Right deck pickup assembly
Left deck pickup assembly
F05-902-12
Urethane sponge
F05-902-13
2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
[7]
[7]
