CHAPTER 5 SERVICE MODE
<JAM>
Indicates jam data.
AA BBBB CCCC DDDD E FFff G HHHHHH IIIII
AA BBBB CCCC DDDD E FFff G HHHHHH IIIII
AA BBBB CCCC DDDD E FFff G HHHHHH IIIII
AA BBBB CCCC DDDD E FFff G HHHHHH IIIII
AA BBBB CCCC DDDD E FFff G HHHHHH IIIII
AA BBBB CCCC DDDD E FFff G HHHHHH IIIII
AA BBBB CCCC DDDD E FFff G HHHHHH IIIII
AA BBBB CCCC DDDD E FFff G HHHHHH IIIII
Item
AA Indicates the numbers of jams
(larger the number, the more past the jam).
BBBB Indicates the date of occurrence.
CCCC Indicates the hour of occurrence.
DDDD Indicates jam recovery time.
E Indicates the location of occurrence.
FFff Jam code
G Indicates the source of paper.
HHHHHH
IIIII Indicates the paper size.
5-12 T
< JAM >
Description
COPYRIGHT © 2001 CANON INC.
< 1/7 > < READY >
F05-201-02
2000 2000 2000 2000
COPIER>DISPLAY
Remarks
1 to 50 (50 max.)
month, day (2 digits each)
24-hour notation
24-hour notation
0: copying machine
1: feeder
2: finisher
FF: jam type
(T05-201-01)
ff: jam sensor
(T05-201-02)
(For the feeder, T05-201-
04.)
(T05-201-03)
