CHAPTER 6 FIXING SYSTEM
b. Halftone Mode (other than text mode)
The machine uses a higher down sequence temperature for modes other than text mode to
prevent faulty fixing of halftone images.
If text mode is used in combination with a non-text mode, the machine will use non-text
mode down sequence throughout the job by placing priority on fixing.
Model
Control
temperature
Control
temperature
6-16 P
iR5000i Down Sequence
50 cpm return mode
40 cpm mode
35 cpm mode
print stop
T06-302-06
iR6000i Down Sequence
60 cpm return mode
50 cpm mode
40 cpm mode
print stop
T06-302-07
COPYRIGHT © 2001 CANON INC.
100-V
180°C
175°C
170°C
165°C
185°C
180°C
175°C
170°C
2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
120/230-V
185°C
180°C
175°C
170°C
