CHAPTER 5 SERVICE MODE
<CST>
Executing Size Auto Adjustment for the Cassette/Manual Feed Tray
C3-STMTR
C3-A4R
C4-STMTR
C4-A4R
Use it to store the paper width basic value for the cassette 3/4.
STMTR width: 139.5 mm, A4R width: 210 mm
Caution For fine adjustment after storing the basic value, make the following selec-
tions: ADJUST>CST-ADJ>C3-STMTR, C3-A4R, C4-STMTR, C4-A4R.
Using the Mode
1) Place STMTR paper in the cassette, and adjust the side guide plate to
suit the STMTR width.
2) Select C3-STMTR (C4-STMTR), and press the OK key.
• The machine executes adjustment automatically, at the end of which the
3) Likewise, repeat steps 1) and 2) for A4R.
MF-A4R
MF-A6R
MF-A4
Use it to store the paper width basic value for the manual feed tray.
Caution For fine adjustment after storing the basic value, make the following selec-
tions: ADJUST>CST-ADJ>MF-A4R, MF-A6R, MF-A4.
Using the Mode
1) Place A4R paper on the manual feed tray, and adjust the side guide to the
A4R width.
2) Select MF-A4R, and press the OK key.
• The machine executes adjustment automatically, at the end of which the
3) Likewise, repeat steps 1) and 2) for A6R and A4.
5-66 T
value is stored.
value is stored.
COPYRIGHT © 2001 CANON INC. 2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
COPIER>FUNCTION
