CHAPTER 1 GENERAL DESCRIPTION
Cleaning/Adjustment
Mail Box Settings
Report Settings
1-24 S
Zoom Fine Adjustment
Feeder Cleaning
Wire Cleaning
Saddle Stitcher
Staple Repositioning
Saddle Stitch Position
Adjustment
Exposure Recalibration
Box Set/Store
Photo Mode
Standard Scan Settings
Additional Functions
Settings
COPYRIGHT © 2001 CANON INC.
Use it to fine-adjust any small
discrepancy between original and
copy images for vertical and horizontal
reproduction ratios. (-1.0% to +1.0%;
0.1% increments; 0%*)
Use it to clean the pickup roller
assembly by feeding paper from the
ADF.
Use it to clean the charging wire.
Use it to edge out the staple unit in
the saddle stitcher unit.
Use it to adjust the position of
saddle stitch. (-2.0 to +2.0 mm;
0.1mm-incrmenets; 0 mm*)
Use it to correct any discrepancy
between original and print images
occurring while the density adjustment
index is kept at the middle. (9 steps; 5*)
Use it to register/set a box. (100 boxes
max.; box No.: 0 to 99; ID No.: 4
digits; file storage period: 1, 2, 3, 6,
12 hr, 1, 2, 3, 7, 30 days, indefinite, 2
hr*; name: 24 characters max.;
initializing a box)
Use it to specify whether to use film
photo mode in conjunction with the box
function. (ON/OFF*)
Use it to change the standard mode for
read settings. (registering/initializing)
Use it to print additional function mode
settings.
* Factory setting.
