APPENDIX
No. Name
6 Environment
sensor checking
sensor
7 Tester extension
pin
8 Tester extension
pin (L-shaped)
Rank:
A: each service person is expected to carry one.
B: each group of five persons is expected to carry one.
C: each workshop is expected to carry one.
A-14
Toll No.
FY9-3014
FY9-3038
FY9-3039
COPYRIGHT © 2001 CANON INC.
Shape Rank
B
A
A
2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
Remarks
Used to check the
environment sensor.
Used when making
electrical checks.
Used when making
electrical checks.
