Dc-Con - Canon Image Reader-A1 iR5000i Service Manual

3.1 DC-CON

Indicates the input/output ports of the DC controller PCB.
<DC-CON (1/8)>
Address Bit Notation
IO-P01 0 PS23
1 PS29
2 PS19
3 PS13
4 PS26
5 PS14
6 PS27
7 PS7
8 PS24
9 PS11
10 PS25
11 PS36
12 PS35
13
14 PS4
15 PS33
IO-P02 0 PS21
1 PS22
2 PS20
3 PS37
4 PS8
5 PS30
6 PS31
7 PS38
8 PS28
9 TS1
10 TS2
11 PS34
12 PS45
13
14
15 MSW1
IO-P03 0 MSW2
1 PS6
2 PS32
COPYRIGHT © 2001 CANON INC.
manual feed paper sensor signal
registration paper sensor signal
right deck re-try sensor signal
cassette 3 paper sensor signal
vertical path 3 paper sensor signal
cassette 4 paper sensor signal
vertical path 4 paper sensor signal
right deck paper sensor signal
vertical path 1 paper sensor signal
left deck paper sensor signal
vertical path 2 paper sensor signal
external delivery sensor signal
internal delivery sensor signal
not used
claw jam sensor signal
left deck feed paper sensor
cassette 3 re-try sensor signal
cassette 4 re-try sensor signal
left deck re-try sensor signal
reversal sensor 1 signal
right pre-registering limit sensor signal
duplexing pre-registration senor signal
duplexing horizontal pre-registration sensor signal
reversal sensor 2 signal
laser write start sensor signal
developing assembly toner sensor signal
hopper toner sensor signal
duplexing paper senor signal
fixing web length detection signal
not used
hopper connector detection signal
waste toner screw lock detection signal
manual feed cover open/closed detection signal
right deck lifter sensor signal
right deck feed paper sensor signal
2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
CHAPTER 5 SERVICE MODE
Description
COPIER>I/O
Remarks
0: paper present
1: paper present
1: paper present
1: paper present
1: paper present
1: paper present
1: paper present
1: paper present
1: paper present
1: paper present
1: paper present
1: paper present
0: paper present
0: paper present
1: paper present
1: paper present
1: paper present
1: paper present
1: paper present
1: limit
1: paper present
0: paper present
1: paper present
1: paper present
0: toner absent
0: toner absent
1: paper present
1: absent
1: disconnected
0: clogged
1: closed
1: paper present
1: paper present
5-21 T
