Access — Enabled.
History—Introduced in MSS Version 3.0. Option for WebAAA fallthru
authentication type changed from web-auth to web-portal in MSS
Version 4.0.
Usage — You cannot set a port's type if the port is a member of a port
VLAN. To remove a port from a VLAN, use the clear vlan command. To
reset a port as a network port, use the clear port type command.
When you change port type, MSS applies default settings appropriate for
the port type. Table 18 lists the default settings that MSS applies when
you set a port's type to ap.
Table 18 Wired Authentication Port Details
Port Parameter
VLAN membership
Spanning Tree
Protocol (STP)
802.1X
Port groups
IGMP snooping
Maximum user sessions 1 (one).
Fallthru authentication
type
For 802.1X clients, wired authentication works only if the clients are
directly attached to the wired authentication port, or are attached
through a hub that does not block forwarding of packets from the client
to the PAE group address (01:80:c2:00:00:03).
Wired authentication works in accordance with the 802.1X specification,
which prohibits a client from sending traffic directly to an authenticator's
MAC address until the client is authenticated. Instead of sending traffic to
the authenticator's MAC address, the client sends packets to the PAE
group address.
The 802.1X specification prohibits networking devices from forwarding
PAE group address packets, because this would make it possible for
multiple authenticators to acquire the same client.
Setting
Removed from all VLANs. You cannot assign a MAP access
port to a VLAN. MSS automatically assigns MAP access ports
to VLANs based on user traffic.
Not applicable
Uses authentication parameters configured for users.
Not applicable
Enabled as users are authenticated and join VLANs.
None
set port type wired-auth 99
