DUAL CLUTCH TRANSMISSION (DCT) (NC700XD/SD)
Linear Solenoid Valve Function Procedures
• If the PCM has a DTC, the function test does not work.
• The function test is not for the quality check of the linear solenoid valve.
• Do not open the throttle while testing the linear solenoid valve function.
Conduct a test of the linear solenoid valves when the linear solenoid valves have been serviced or replaced.
1. Connect the HDS pocket tester.
2. Select the "DRIVE TRAIN MODE MENU".
3. Select the "FUNCTION TEST" and then select the "Linear Solenoid".
4. Select the "Linear Solenoid 1" or "Linear Solenoid 2".
5. Start the engine and let it idle.
6. Make sure that the transmission is in neutral position.
7. Select the "Drive Linear Solenoid To 0 kPa", "Drive Linear Solenoid To 400 kPa" or "Drive Linear Solenoid To 800 kPa" mode.
Measure the linear solenoid current at each mode.
SPECIFICATIONS
Clutch clearance
EOT sensor resistance (20°C/68°F)
TORQUE VALUES
ITEM
Solenoid valve stopper plate bolt
Right crankcase cover wire clamp
bolt
Linear solenoid valve body
mounting bolt
Shift spindle angle sensor bolt
Primary drive gear mounting bolt
Reduction gear cover bolt
TR sensor bolt
Shift control motor bolt
Shift drum center bolt
Drum shifter guide plate bolt
Clutch line EOP sensor
EOT sensor
12-4
ITEM
THREAD
Q'TY
DIA. (mm)
1
2
6
1
1 10
3
1
3
1
2
3 10
1 10
STANDARD
0.9 – 1.1 (0.035 – 0.043)
2.5 – 2.8 kΩ
TORQUE
N·m (kgf·m, lbf·ft)
6 12 (1.2, 9)
6 12 (1.2, 9)
6 –
6 12 (1.2, 9)
93 (9.5, 69)
6 14 (1.4, 10)
6 12 (1.2, 9)
6 14 (1.4, 10)
8 23 (2.3, 17)
6 12 (1.2, 9)
19.6 (2.0, 14)
14 (1.4, 10)
Unit: mm (in)
SERVICE LIMIT
2.0 (0.08)
–
REMARKS
Apply locking agent to the threads.
Coating width: 6.5 ± 1.0 mm (0.26 ±
0.04 in) except 2.0 ± 1.0 mm (0.08 ±
0.04 in) from tip
Apply locking agent to the threads.
Coating width: 6.5 ± 1.0 mm (0.26 ±
0.04 in) except 2.0 ± 1.0 mm (0.08 ±
0.04 in) from tip
For tightening sequence (page 12-
101)
Apply engine oil to the threads and
seating surface.
Apply locking agent to the threads.
Coating width: 6.5 ± 1.0 mm (0.26 ±
0.04 in) except 2.0 ± 1.0 mm (0.08 ±
0.04 in) from tip
Apply locking agent to the threads.
Coating width: 6.5 ± 1.0 mm (0.26 ±
0.04 in) except 2.0 ± 1.0 mm (0.08 ±
0.04 in) from tip
Apply engine oil to the threads and
seating surface.
