  • Page 1 OW N E R’S M A N UA L 2024 NC750X...
  • Page 2 This publication includes the latest production information available before printing. Honda Motor Co., Ltd. reserves the right to make changes at any time without notice and without incurring any obligation.
  • Page 3 Welcome Congratulations on your purchase of a new When service is required, remember that Honda vehicle. Your selection of a Honda your Honda dealer knows your vehicle best. makes you part of a worldwide family of If you have the required mechanical “know- satisfied customers who appreciate Honda's how”...
  • Page 4 A Few Words About Safety Your safety, and the safety of others, is very DANGER important. Operating this vehicle safely is an You WILL be KILLED or SERIOUSLY important responsibility. HURT if you don’t follow instructions. To help you make informed decisions about safety, we have provided operating WARNING procedures and other information on safety...

  • Page 5: Table Of Contents

    Contents Vehicle Safety P. 2 Operation Guide P. 18 Maintenance P. 99 Troubleshooting P. 142 Information P. 155 Specifications P. 181...

  • Page 6: Vehicle Safety

    Vehicle Safety This section contains important information for safe riding of your vehicle. Please read this section carefully. Safety Guidelines ..........P. 3 Safety Labels............P. 7 Safety Precautions..........P. 9 Riding Precautions ..........P. 10 Accessories & Modifications......P. 15 Loading ..............

  • Page 7: Safety Guidelines

    Safety Guidelines Safety Guidelines Before Riding Make sure that you are physically fit, mentally Follow these guidelines to enhance your safety: focused, and free of alcohol and drugs. Check Perform all routine and regular inspections ● that you and your passenger are both wearing specified in this manual.

  • Page 8: Ride Defensively

    Be prepared to stop quickly or perform an evasive maneuver. Keep Your Honda in Safe Condition Make Yourself Easy to See It's important to keep your vehicle properly maintained and in safe riding condition.
  • Page 9 Safety Guidelines Inspect your vehicle before every ride and thoroughly checked at a qualified service facility perform all recommended maintenance. Never as soon as possible. exceed load limits ( P. 16), and do not modify Emergency Shut-down Procedure for your vehicle or install accessories that would Vehicles Equipped with Dual Clutch make your vehicle unsafe ( P.

  • Page 10: Carbon Monoxide Hazard

    Safety Guidelines WARNING Carbon Monoxide Hazard Exhaust contains poisonous carbon monoxide, a Running the engine of your vehicle colorless, odorless gas. Breathing carbon while in an enclosed or even partially monoxide can cause loss of consciousness and enclosed area can cause a rapid build- may lead to death.

  • Page 11: Safety Labels

    Safety Labels Safety Labels serious injury. Read these labels carefully and don't remove them. Safety and information labels on your vehicle If a label comes off or becomes hard to read, provide important safety information and may contact your dealer for a replacement. warn you of potential hazards that could cause Continued...
  • Page 12 Safety Labels...

  • Page 13: Safety Precautions

    Safety Precautions Safety Precautions Must fit comfortably but securely, with the ● chin strap fastened Ride cautiously and keep your hands on the Face shield with unobstructed field of vision ● ● handlebar and feet on the footpegs. or other approved eye protection Instruct your passenger to keep their hands Look for a DOT (Department of ●...

  • Page 14: Riding Precautions

    Riding Precautions Riding Precautions Boots or Riding Shoes Sturdy boots with non-slip soles and ankle protection Break-in Period Jacket and Pants During the first 300 miles (500 km) of running, follow these guidelines to ensure your vehicle's Protective, highly visible, long-sleeved jacket future reliability and performance.
  • Page 15 Riding Precautions Exercise caution on low traction surfaces. The brake lever and pedal may recoil slightly ● ● The tires slip more easily on such when applying the brakes. This is normal. surfaces and braking distances are Always use the recommended front/rear ●...
  • Page 16 Riding Precautions Parking with the Side Stand Parking Stop the engine. Park on a firm, level surface. ● Push the side stand down. If you must park on a slight incline or loose ● Slowly lean the vehicle to the left until its surface, park so that the vehicle cannot weight rests on the side stand.
  • Page 17 Riding Precautions Refueling and Fuel Guidelines Follow these guidelines to protect the engine, fuel system and catalytic converter: Use only unleaded gasoline. ● Use the recommended octane number. ● Using lower octane gasoline will result in decreased engine performance. Do not use fuels containing a high ●...
  • Page 18 Torque Control may not compensate for rough Honda Selectable Torque Control road conditions or rapid throttle operation. When the Honda Selectable Torque Control Always consider road and weather conditions, detects rear wheel spin during acceleration, the as well as your skills and condition, when system will limit the amount of torque applied applying throttle.

  • Page 19: Accessories & Modifications

    We strongly advise that you do not add any seriously hurt or killed. accessories that were not specifically designed or approved for your vehicle by Honda or make Follow all instructions in this owner's modifications to your vehicle from its original manual regarding accessories and design.

  • Page 20: Loading

    Loading Loading WARNING Overloading or improper loading can Carrying extra weight affects your vehicle's ● cause a crash and you can be seriously handling, braking and stability. hurt or killed. Always ride at a safe speed for the load you are carrying.
  • Page 21 This page intentionally left blank.

  • Page 22: Parts Location

    Parts Location NC750XA Battery (P.120) Main fuse (P.154) Fuse box (P.153) Front brake fluid reservoir (P.130) Front brake lever (P.140) Throttle grip (P.139) Engine oil fill cap/dipstick (P.126) Coolant reserve tank (P.128) Lower cowl (P.123) Rear brake pedal Rear brake fluid reservoir (P.130)
  • Page 23 Clutch lever (P.136) Luggage box (P.96) Maintenance lid (P.125) Rear seat (P.94) Fuel fill cap (P.94) Rear suspension spring preload adjuster (P.141) Drive chain (P.134) Shift lever (P.87) Side stand (P.133) Continued...
  • Page 24 Parts Location (Continued) NC750XD Battery (P.120) Main fuse (P.154) Fuse box (P.153) Front brake fluid reservoir (P.130) Front brake lever (P.140) Throttle grip (P.139) Engine oil fill cap/dipstick (P.126) Coolant reserve tank (P.128) Lower cowl (P.124) Rear brake pedal Rear brake fluid reservoir (P.130)
  • Page 25 Parking brake lever (P.76) Luggage box (P.96) Maintenance lid (P.125) Rear seat (P.94) Fuel fill cap (P.94) Rear suspension spring preload adjuster (P.141) Drive chain (P.134) Side stand (P.133)
  • Page 26 Instruments (up) button (down) button MODE button Display Check When the ignition switch is turned to the ON position, all the mode and digital segments will show. If any part of these displays does not come on when it should, have your dealer check for problems.
  • Page 27 Clock (12-hour or 24-hour display) Tachometer red zone To set the clock: (excessive engine rpm range) (P.47) D level Speedometer Tachometer NOTICE Do not operate the engine in the tachometer red zone. Excessive engine speed can adversely affect engine life. Continued...
  • Page 28 Instruments (Continued) Fuel gauge Remaining fuel when only 1st (E) segment starts flashing: approximately 0.79 US gal (3.0 L) The reserve tripmeter display and reserve fuel consumption display show at the same time. If the fuel gauge indicator flashes in a repeat pattern or turns off: (P.150)

  • Page 29: Gear Position Indicator

    Gear position indicator NC750XA The gear position is shown in the gear position indicator. Neutral (N) is not displayed when the transmission is in neutral position. “-” appears when the transmission is not shifted properly. NC750XD The gear position is shown in the gear position indicator. The indicator may flash if: The front wheel leaves the ground.
  • Page 30 Instruments (Continued) Press the button to move the cursor to a desired display. MODE Cursor Riding mode Riding mode (P.77) INFO 1 display Cursor INFO 2 display INFO 2 display INFO 1 display (P.34) (P.28) Cursor Press the button MODE...
  • Page 31 LCD backlight brightness switching The brightness of the display can be switched to H (high) or L (low). When the (up) button is pressed and held, the following display appears and the brightness is set. You can also adjust the H (high) or L (low) brightness level. (P.48) (P.49) H (high) L (low)
  • Page 32 Instruments (Continued) INFO 1 display You can select the following: Odometer [TOTAL] ● Tripmeter [TRIP A/B] ● Subtraction tripmeter [-TRIP] ● Date [TODAY] ● Reserve tripmeter [RES] ●...
  • Page 33 Changing the INFO 1 display Select the INFO 1 display. (P.26) Press the (up) or the (down) button until the desired indication is displayed. Press the button. The INFO 1 display is set, and then the cursor moves to the INFO 2 MODE display.
  • Page 34 Instruments (Continued) Odometer [TOTAL] Total distance ridden. When “------” is displayed, go to your dealer for service. Tripmeter A/B [TRIP A/B] Distance ridden since the tripmeter was reset. When “----.-” is displayed, go to your dealer for service. To reset the tripmeter: (P.32) Subtraction Tripmeter [-TRIP] Distance travelled is subtracted from a preset figure, since the subtraction trip was set up.
  • Page 35 Reserve tripmeter [RES] Distance ridden since the 1st (E) segment of the fuel gauge starts flashing. When the 1st (E) segment of the fuel gauge starts flashing, the INFO 1 display switches to the reserve tripmeter. You should refill the tank as soon as possible. Display range: 0.0 to 9999.9 mile (km) When “----.- ”...

  • Page 36: Average Fuel Mileage

    Instruments (Continued) To reset the tripmeter, average fuel mileage, fuel consumption, average speed and trip time To reset the tripmeter A, average fuel mileage, fuel consumption, average speed and trip time (these are based on tripmeter A) together, press and hold the button while tripmeter A or MODE odometer and average fuel mileage, fuel consumption, average speed or trip time is displayed.
  • Page 37 To reset tripmeter B, average fuel mileage, fuel consumption, average speed and trip time (these are based on tripmeter B) together, press and hold the button while tripmeter B MODE is displayed. Tripmeter B Average fuel Fuel mileage Trip time consumption Average speed Then, the display will return to the previous selection.
  • Page 38 Instruments (Continued) INFO 2 display You can select the following: Current fuel mileage ● Average fuel mileage ● Fuel consumption ● Average speed ● Trip time ● Running time ● Battery voltage meter ● Reserve fuel consumption ●...
  • Page 39 Changing the INFO 2 display Select the INFO 2 display. (P.26) Press the (up) or the (down) button until the desired indication is displayed. Press the button. The INFO 2 display is set, and then the cursor moves to the riding mode MODE display.
  • Page 40 Instruments (Continued) When the 1st (E) segment of the fuel gauge starts flashing, the current fuel mileage, average fuel mileage, fuel consumption, average speed or trip time switches to the reserve fuel consumption.
  • Page 41 Current fuel mileage Displays the current or instant fuel mileage. Display range: 0.0 to 300.0 mile/gal (km/L, L/100km or mile/L) When your speed is less than 3 mph (5 km/h): “---.-” is displayed. ● More than 300.0 L/100km: “---.-” is displayed. ●...
  • Page 42 Instruments (Continued) Fuel consumption Displays the fuel consumption since the selected tripmeter was reset. The fuel consumption will be calculated based on value displayed on the tripmeter (A or B) selected. When the tripmeter B is selected on the INFO 1 display, the fuel consumption of the tripmeter B is displayed.
  • Page 43 Average speed Display range: 0 to 124 mph (0 to 199 km/h) The average speed will be calculated based on value displayed on the tripmeter (A or B) selected. When the tripmeter B is selected on the INFO 1 display, the average speed of the tripmeter B is displayed.

  • Page 44: Running Time

    Instruments (Continued) Trip time Displays the operating time since the selected tripmeter was reset. The trip time will be calculated based on value displayed on the tripmeter (A or B) selected. When the tripmeter B is selected on the INFO 1 display, the trip time of the tripmeter B is displayed.
  • Page 45 Reserve fuel consumption Displays the fuel consumption since the 1st (E) segment of the fuel gauge starts flashing. When the 1st (E) segment of the fuel gauge starts flashing, the current fuel mileage, average fuel mileage, fuel consumption, average speed, trip time, running time or battery voltage meter switches to the reserve fuel consumption.
  • Page 46 Instruments (Continued) Display Setting Select the items you want to set from the following setting modes. Multicolor line information setting Press and hold the (up) or the (down) button and the button MODE • Press the button MODE Ordinary display •...
  • Page 47 ADJUST mode The following items can be changed sequentially. Time format setting ● Date setting ● Clock setting ● Backlight brightness H (high) adjustment ● Backlight brightness L (low) adjustment ● Activating/deactivating of tripmeter A, average fuel mileage, fuel consumption, average ●...
  • Page 48 Instruments (Continued) Ordinary display ADJUST mode Time format setting Subtraction trip setting Date setting Changing the fuel mileage meter unit Clock setting Changing the speed and mileage unit Backlight brightness H (high) adjustment Activating/deactivating of tripmeter A, average fuel mileage, fuel consumption, average speed and trip time automatic reset mode Backlight brightness L (low) adjustment Press and hold the...
  • Page 49 If the ignition switch is turned to the OFF 1 Time format setting: position, or if none of the You can switch the time format between 12 MODE (up) or (down) buttons are pressed hour format or 24 hour format. for about 30 seconds, the control will Turn the ignition switch to the ON position.
  • Page 50 Instruments (Continued) 2 Date setting: Press the (up) button or the (down) button until the desired month is Press the (up) button or the displayed. (down) button until the desired year is Press and hold the (up) button displayed. or the (down) button to Press and hold the (up) button...
  • Page 51 Press the button. The date is set, 3 Clock setting: MODE and the display moves to the clock setting. Press the (up) button or the (down) button until the desired hour is displayed. Press and hold the (up) button or the (down) button to advance the hour fast.
  • Page 52 Instruments (Continued) Press the (up) button or the 4 Backlight brightness H (high) (down) button until the desired minute is adjustment: displayed. You can adjust the brightness to one of five Press and hold the (up) button levels. or the (down) button to Press the (up) button or the...
  • Page 53 5 Backlight brightness L (low) adjustment: You can adjust the brightness to one of five levels. Press the (up) button or the (down) button. The brightness is switched. Press the button. The brightness L MODE (low) is set, and then the display moves to activating/deactivating of tripmeter A, average fuel mileage, fuel consumption, average speed and trip time automatic reset...
  • Page 54 Instruments (Continued) 6 Activating/deactivating of tripmeter A, average fuel mileage, fuel consumption, average speed and trip time automatic reset mode: You can activate or deactivate the automatic reset mode (trip time is automatically reset by refueling until the fuel gauge reaches two segments or more and you ride your vehicle for at least 0.06 mile (0.1 km).) The default setting is "On".
  • Page 55 Press the button. The activation/ 7 Changing the speed and mileage unit: MODE deactivation of automatic reset mode is set, Press the (up) button or the and then the display moves to the changing (down) button to select either “km/h” & of the speed and mileage unit.
  • Page 56 Instruments (Continued) 8 Changing the fuel mileage meter unit: 9 Subtraction trip setting: Press the (up) button or the You can adjust the value of the subtraction (down) button to select “L/100km” or “km/L”. trip. The message of "UNIT FUEL CON" scrolls The preset figure is displayed and the fourth in INFO 1 display.
  • Page 57 Repeat the steps for the second and first digits. Press the button. The trip distance is MODE set, and then the display will return to the ordinary display. Continued...
  • Page 58 Instruments (Continued) LINE mode Press and hold the (up) or the The following items can be changed (down) button and the button MODE sequentially. Press the button Shift up rev setting MODE ● Shift width setting ● Ordinary display Time sign setting ●...
  • Page 59 1 Shift up rev setting Each time the (up) button or the (down) button is pressed, the You can adjust the shift up point. tachometer bar and RPM value in INFO 2 Turn the ignition switch to the ON position. display increase or decrease by 200 r/min Select the LINE mode.
  • Page 60 Instruments (Continued) 2 Shift width setting You can set the interval at which the tachometer flashes to indicate the RPM has reached a shift up point. The INFO 2 display starts flashing, and the message of "SHIFT WIDTH" scrolls in INFO 1 display.
  • Page 61 When the multicolor line information is set to Ex: When shift up rev setting is 6,000 r/min Rev up linkage mode (color mode) (rpm) and shift width setting is 600 r/min (P.64) (rpm). Multicolor line r/min (rpm) Yellow 4,800 When the multicolor line information is set to Rev up linkage mode (white color mode) Amber 5,400...
  • Page 62 Instruments (Continued) 3 Time sign setting 4 Fuel sign setting You can display the time with a multicolor You can set the fuel sign with a multicolor line. line. When the minutes of the clock change from When the 1st (E) segment of the fuel gauge 59 to 00, the multicolor line will blink three starts flashing, the line will light in amber for times when the setting is on.
  • Page 63 5 Switch sign setting SP Setting Mode You can set the switch sign with a multicolor Inputting the ending message: line. Ending message can input 6 letters. When the (up) button, Turn the ignition switch to the ON position. Select the SP mode. (down) button, or button is pressed, MODE...
  • Page 64 Instruments (Continued) Press the button. The letter is set, MODE and the next letter will start flashing. Follow (Space) the procedure steps until the last letter is set. After the ending message has been set, the display returns to the ordinary display. Selecting letters at the ending display: When the (up) button or the...
  • Page 65 Multicolor line information setting Multicolor line You can show the riding conditions by setting the multicolor line information. Except during user setting of riding mode. (P.80) The following items can be set sequentially. Color OFF mode ● Rev up linkage mode (white color mode) ●...
  • Page 66 Instruments (Continued) Ordinary display Press and hold the (down) button • Press the button MODE Color OFF mode • Press and hold the MODE button Rev up linkage mode • Press and hold the (white color mode) (up) button Press the (up) button Rev up linkage mode (color mode)
  • Page 67 Order of priority for the color: ECO mode > Rev up linkage mode Gear position linkage mode Riding mode linkage mode Color OFF mode Color mode is deactivated. Rev up linkage mode (white color mode) When the number of engine revolution reaches the shift up point you have set, the color of the multicolor line blinks in white.
  • Page 68 Instruments (Continued) Rev up linkage mode (color mode) When the number of engine revolutions reaches the shift up point you have set, the color of the multicolor line will change. This indicates to shift up. Ex: When shift up rev setting is 6,000 r/min (rpm) and shift width setting is 600 r/min (rpm). Multicolor line r/min (rpm) Yellow...
  • Page 69 Gear position linkage mode Depending on the gear position, the multicolor line changes as follows. Gear position Color Yellow Pink Violet Blue Aqua Green The gear position linkage mode includes Rev up linkage mode (white color mode). Riding mode linkage mode Depending on the riding mode, the multicolor line changes as follows.
  • Page 70 Indicators If one of these indicators does not come on when it should, have your dealer check for problems. Torque Control OFF indicator Comes on when the Torque Control is turned off. Torque Control indicator Comes on when the ignition switch is turned to the ●...

  • Page 71: Neutral Indicator

    High coolant temperature indicator Comes on briefly when the ignition switch is turned to the ON position. If it comes on while riding: (P.144) ABS (Anti-lock Brake System) indicator Comes on when the ignition switch is turned to the ON position. Goes off when your speed reaches approximately 6 mph (10 km/h).
  • Page 72 Indicators (Continued) Left turn signal indicator Right turn signal indicator Low oil pressure indicator Comes on when the ignition switch is turned to the ON position. Goes off when the engine starts. If it comes on while the engine is running: (P.145)
  • Page 73 PGM-FI (Programmed Fuel Injection) malfunction indicator lamp (MIL) Comes on briefly when the ignition switch is turned to the ON position. If it comes on while the engine is running: (P.146) Parking brake indicator NC750XD Lights as a reminder that you have not released the parking brake lever.
  • Page 74 Switches Ignition Switch Switches the electrical system on/off, locks the steering. Key can be removed when in the OFF or LOCK position. Steering Lock: (P.75) Turns electrical system on for starting/riding. Turns engine off. LOCK Left handlebar switches Right handlebar switches Locks steering.
  • Page 75 Left handlebar switches Used to operate and set the display. NC750XA (P.22) Also used to change the riding mode. (P.77) Hazard switch Switchable when the ignition switch is on. (up) button (down) button Headlight dimmer switch/ button MODE Passing light control switch •...
  • Page 76 Switches (Continued) NC750XD Used to operate and set the display. (P.22) Also used to change the riding mode. (P.77) Hazard switch Switchable when the ignition switch is on. Headlight dimmer switch/ (up) button Passing light control switch • : High beam (down) button •...

  • Page 77: Right Handlebar Switches

    Right handlebar switches NC750XA Engine stop switch/ Start button Should normally remain in the (Run) position. In an emergency, switch to the (Stop) position to stop the engine. Continued...
  • Page 78 Switches (Continued) NC750XD Engine stop switch/ Start button Should normally remain in the (Run) position. In an emergency, switch to the (Stop) position to stop the engine. A/M switch To shift between the AT MODE and MT MODE. (P.92) N-D switch To shift between Neutral and AT MODE.

  • Page 79: Ignition Key

    Steering Lock Locking Turn the handlebar all the way to the left. Lock the steering when parking to help Push the key down, and turn the ignition prevent theft. switch to the LOCK position. A U-shaped wheel lock or similar device is Jiggle the handlebar if the lock is difficult also recommended.

  • Page 80: Parking Brake Lever

    Parking Brake Locking NC750XD Pull the parking brake lever (a) back to lock Parking brake lever and Release button the rear wheel. Be sure the parking brake is applied while Be sure the release button pops out and the parking and warming up the engine. parking brake lever is not released.

  • Page 81: Riding Mode

    Riding mode You can change the riding mode. EB level The riding mode consists of the following P level parameters. Current riding mode P: Engine power output level EB: Engine brake level T: Torque control level NC750XD D: DCT level T level NC750XD D level...

  • Page 82: Initial Setting

    Riding mode (Continued) There are four available riding modes: [RAIN]: Good for stable riding on slippery surfaces such as rainy conditions. [SPORT], [STANDARD], [RAIN] and [USER]. You cannot change the initial setting levels for [STANDARD], [RAIN], and [SPORT]: This mode is suitable for sports [SPORT].
  • Page 83 P level (Engine power output level) EB level (Engine brake level) P level has three setting levels. EB level has three setting levels. Available setting range: 1 to 3 Available setting range: 1 to 3 Level 1 has the least power. Level 1 has the weakest engine braking Level 3 has the most power.

  • Page 84: Mode Button

    Riding mode (Continued) Selecting the riding mode Stop the vehicle. Select the riding mode display. (P.26) SPORT Press the (up) or (down) button with the throttle fully closed. STANDARD (up) button RAIN USER (down) button Press the (up) button button MODE Press the (down) button...
  • Page 85 Setting the riding mode Press the (up) or (down) button until the desired level is displayed. NC750XA T level can be changed to off by pressing You can change the P, EB and T levels on the and holding the (down) button.
  • Page 86 Riding mode (Continued) Press and hold button MODE Press the MODE button Press the (up) button Press the (down) button NC750XD Press and hold (down) button...

  • Page 87: Starting The Engine

    Starting the Engine NC750XA NOTICE Start your engine using the following • If the engine does not start within 5 seconds, procedure, regardless of whether the engine turn the ignition switch to the OFF position and wait 10 seconds before trying to start is cold or warm.
  • Page 88 Starting the Engine (Continued) Press the start button with the throttle If the engine does not start: completely closed. Open the throttle fully and press the start If you cannot start the engine, open the button for 5 seconds. throttle slightly (about 0.1 in [3 mm], Repeat the normal starting procedure.
  • Page 89 NC750XD NOTICE Start your engine using the following • If the engine does not start within 5 seconds, procedure, regardless of whether the engine turn the ignition switch to the OFF position and wait 10 seconds before trying to start is cold or warm.
  • Page 90 Starting the Engine (Continued) Press the start button with the throttle When you stop the engine completely closed. To stop the engine, shift the transmission to If you cannot start the engine, open the Neutral ( indicator comes on). throttle slightly (about 0.1 in [3 mm], If you turn the ignition switch to the OFF without freeplay) and press the start position when the vehicle is in gear, the...

  • Page 91: Shifting Gears

    Shifting Gears Recommended Shift Points NC750XA Your vehicle transmission has 6 forward Shifting Up gears in a one-down, five-up shift pattern. From 1st to 2nd 12 mph (20 km/h) From 2nd to 3rd 19 mph (30 km/h) From 3rd to 4th 25 mph (40 km/h) From 4th to 5th 31 mph (50 km/h)
  • Page 92 Shifting Gears (Continued) Recommended Shift Points NC750XD Your vehicle is equipped with an Shifting Up automatically controlled 6-speed From 1st to 2nd 12 mph (20 km/h) transmission. It can be shifted automatically From 2nd to 3rd 20 mph (32 km/h) (by AT MODE) or manually (by MT MODE).
  • Page 93 Dual Clutch Transmission The Dual Clutch Transmission system runs a In order to respond to rider demands in a self check immediately after starting the broad range of situations, the transmission is engine. equipped with two operating modes, AT You cannot change AT MODE (D) for a few MODE (D) (automatic shift for regular seconds.
  • Page 94 Shifting Gears (Continued) Neutral (N): Neutral is selected When you can change between N and D automatically when you turn the ignition Vehicle is stopped and the engine is idling. Throttle is completely closed. It is not switch to the ON position. possible to change from Neutral to D mode If neutral is not selected when you turn while the throttle is applied.
  • Page 95 AT MODE: In this mode, the gears are MT MODE (6-speed manual operation): shifted automatically according to your riding In this mode, you can choose between 6 conditions. gears. And also using the shift up switch (+) or shift down switch (−), you can temporarily shift up or down.
  • Page 96 Shifting Gears (Continued) Changing between Neutral and AT N-D switch MODE/MT MODE Changing from Neutral (N) to AT MODE Press the D side on the N-D switch (a). Parameter display changes to D (b), “1” is shown in the gear position indicator and first switch gear is selected.

  • Page 97: Shift Limit

    Riding in MT MODE Gear shift operation Shift up and down with the shift up switch (+) Shifting Up: and shift down switch (−). Press the shift up switch (+) (f). The selected gear is shown on the gear Shifting Down: position indicator.

  • Page 98: Ignition Key

    Refueling The rear seat must be opened to refuel this Open vehicle. Insert the ignition key into the lock and turn the key counterclockwise. Rear Seat Pull up the front of the rear seat. Ignition key Close Pull up the rod upward. Push down the front of the rear seat until it locks in place.
  • Page 99 Fuel type: Unleaded gasoline only Arrow marks Lower edge of Recommended fuel octane number: filler neck Pump Octane Number (PON) 86 or higher. Tank capacity: 3.73 US gal (14.1 L) Refueling and Fuel Guidelines (P.13) Fuel fill cap Opening the Fuel Fill Cap Open the rear seat.

  • Page 100: Storage Equipment

    Storage Equipment Luggage Box Open Insert the ignition key into the lock and turn the key clockwise. Ignition key Pull up the front of the luggage box lid. Close Push down the front of the luggage box lid Lock until it locks in place. Make sure that the tab is locked securely in position to pull up the front of the luggage box lid lightly.
  • Page 101 A helmet can be stored in the luggage box. Tool Kit/Document Bag Store the helmet face-up. The tool kit and document bag are stored on the maintenance lid (in the luggage box) by the rubber strap. Helmet Document bag Tool kit Rubber strap Some helmets may not fit in the...
  • Page 102 Storage Equipment (Continued) Helmet holder Use the helmet holder only when parked. The helmet holder is located under the rear Opening the rear seat. (P.94) seat. A helmet set wire is in the tool kit. WARNING Helmet set wire Riding with a helmet attached to the holder can interfere with the rear wheel or suspension and could cause a crash in which you can be seriously hurt or...

  • Page 103: Maintenance

    Please read “Importance of Maintenance” and “Maintenance Fundamentals” carefully before attempting any maintenance. Refer to “Specifications” for service data. An optional larger tool kit may be available. Check with your Honda dealer's parts department. Importance of Maintenance ......P. 100 Side Stand ............P. 133 Maintenance Schedule........

  • Page 104: Importance Of Maintenance

    Importance of Maintenance For information about the exhaust emission and Importance of Maintenance noise emission requirements of the U.S. Keeping your vehicle well-maintained is Environmental Protection Agency (EPA), the absolutely essential to your safety and to California Air Resources Board (CARB), and the protect your investment, obtain maximum Environment and Climate Change Canada performance, avoid breakdowns, and reduce air...

  • Page 105: Maintenance Safety

    Importance of Maintenance Maintenance Safety Always read the maintenance instructions before you begin each task and make sure that you have the tools, parts, and skills required. We cannot warn you of every conceivable hazard that can arise in performing maintenance.

  • Page 106: Maintenance Schedule

    Maintenance work should be performed in owner. accordance with Honda's standards and specifications by properly trained and equipped technicians. Your dealer meets all of these requirements. All scheduled maintenance is considered a normal owner operating cost and will be charged to you by your dealer.
  • Page 107 Maintenance Legend mechanically skilled. Inspect (clean, adjust, lubricate, or replace, if necessary) Procedures are provided in an official Honda Service Replace Manual (2 P. 173). Lubricate : Technical. In the interest of safety, have your vehicle Clean serviced by your dealer.
  • Page 108 Maintenance Schedule Frequency Items × 1,000 mi Regular Refer to Replace page × 1,000 km 12.8 19.2 25.6 32.0 38.4 Drive Chain Every 600 mi (1,000 km): Drive Chain Slider – Brake Fluid 2 Years Brake Pads Wear Brake System Brake Light Switch Brake Lock Operation Headlight Aim...

  • Page 109: Maintenance Record

    Maintenance Record Distance Odometer Date Performed By: Notes 600 miles (1,000 km) 4,000 miles (6,400 km) 8,000 miles (12,800 km) 12,000 miles (19,200 km) 16,000 miles (25,600 km) 20,000 miles (32,000 km) 24,000 miles (38,400 km) 28,000 miles (44,800 km) 32,000 miles (51,200 km) 36,000 miles (57,600 km) 40,000 miles (64,000 km)

  • Page 110: Maintenance Fundamentals

    Maintenance Fundamentals Check the following items after you get on your Pre-ride Inspection vehicle: To ensure safety, it is your responsibility to Throttle action moves smoothly without ● perform a pre-ride inspection and make sure binding P. 139 that any problem you find is corrected. A pre- Brake lever and pedal operate normally ●...
  • Page 111 Maintenance Fundamentals Also, check the odometer reading against the Periodic Checks Maintenance Schedule and perform all You should also perform other periodic maintenance that is due. P. 102 maintenance checks at least once a month regardless of how often you ride, or more often if you ride frequently.
  • Page 112 Maintenance Fundamentals WARNING Replacing Parts Always use Honda Genuine Parts or their Installing non-Honda parts may make equivalents to ensure reliability and safety. your vehicle unsafe and cause a crash in When ordering colored components, specify which you can be seriously hurt or the model name, color, and code mentioned on killed.
  • Page 113 Maintenance Fundamentals Electrolyte splashes into your eyes: Battery ● Wash your eyes repeatedly with cool Your vehicle has a maintenance-free type battery. water for at least 15 minutes. Using water You do not have to check the battery electrolyte under pressure can damage your eyes. level or add distilled water.
  • Page 114 30 days using a charger designed specifically for If the terminals are heavily corroded, clean your Honda, which can be purchased from your and polish the terminals with a wire brush or dealer. Read the information that came with sandpaper.
  • Page 115 Bump starting is also not recommended. NOTICE Installing non-Honda electrical accessories can NOTICE overload the electrical system, discharging the Replacing a fuse with one that has a higher battery and possibly damaging the system.
  • Page 116 “Resource Conserving” on the circular API For recommended engine oil, see service symbol. “Specifications.” P. 182 If you use non-Honda engine oil, check the label to make sure that the oil satisfies all of the following standards: JASO T 903 standard : MA ●...
  • Page 117 Wipe up spills immediately and wash thoroughly. Also inspect the drive sprocket and driven Recommended brake fluid: sprocket. If either has worn or damaged teeth, Honda DOT 4 Brake Fluid or equivalent have the sprocket replaced by your dealer. WARNING Clean filler cap before removing. Use only DOT 4 fluid from a sealed container.

  • Page 118: Recommended Coolant

    Recommended Coolant After cleaning, wipe dry and lubricate with the recommended lubricant. Pro Honda HP Coolant is a pre-mixed solution of antifreeze and distilled water. Recommended lubricant: Pro Honda HP Chain Lube or equivalent...
  • Page 119 Maintenance Fundamentals Tires (Inspecting/Replacing) NOTICE Using coolant not specified for aluminum Checking the Air Pressure engines or tap/mineral water can cause Visually inspect your tires and use an air corrosion. pressure gauge to measure the air pressure at least once a month or any time you think the Crankcase Breather tires look low.
  • Page 120 Maintenance Fundamentals Inspecting for Damage Inspecting for Abnormal Wear Inspect the tires for Inspect the tires for cuts, slits, or cracks that signs of abnormal wear expose fabric or cords, on the contact surface. or nails or other foreign objects embedded in the side of the tire or the tread.
  • Page 121 Maintenance Fundamentals WARNING Inspecting Tread Depth Inspect the tread wear indicators. If they Riding on tires that are excessively worn become visible, replace the tires immediately. or improperly inflated can cause a crash For safe riding, you should replace the tires in which you can be seriously hurt or when the minimum tread depth is reached.
  • Page 122 Always use the size and type of tires speed rating, and load range. recommended in this owner's manual. Have the wheel balanced with Honda ● Genuine balance weights or equivalent after the tire is installed.

  • Page 123: Tire Identification Number (Tin)

    Maintenance Fundamentals Tire Identification Number (TIN) Tire Service Life The tire identification number (TIN) is a group The service life of your tires is dependent on of numbers and letters located on the sidewall many factors, including, but not limited to, of the tire.

  • Page 124: Removing & Installing Body Components

    Removing & Installing Body Components Battery Remove the maintenance lid. P. 125 Unhook the battery band. Positive terminal Negative terminal Disconnect the negative - terminal from the battery. Disconnect the positive + terminal from the battery. Remove the battery, taking care not to drop the terminal nuts.

  • Page 125: Clip

    Removing & Installing Body Components Clip Clip Installation Removal Center pin Push the bottom of the center pin. Insert the clip into the hole. Press down on the center pin to release Press down on the center pin to lock the the lock.

  • Page 126: Harness Band Clip

    Removing & Installing Body Components Harness Band Clip Harness Band Clip Installation Install the harness band clip until it seats Removal properly. Pull the harness band clip while pressing both sides of the anchor. Anchor...

  • Page 127: Lower Cowl

    Removing & Installing Body Components Lower Cowl Lower Cowl Removal Remove the bolts. NC750XA Remove the lower cowl by releasing its prongs from the grommets. Grommets Harness band clip Remove the lower cowl while releasing the harness band clip. P. 122 Be careful not to damage the wire harness.
  • Page 128 Removing & Installing Body Components Lower Cowl Removal NC750XD Remove the bolts. Bolt Grommets Remove the lower cowl by releasing its prongs from the grommets. Remove the lower cowl while releasing the harness band clip. P. 122 Be careful not to damage the wire harness.

  • Page 129: Maintenance Lid

    Removing & Installing Body Components Maintenance Lid Maintenance Lid Removal Open the luggage box. P. 96 Maintenance lid Remove the clips. P. 121 Remove the maintenance lid. Installation Install the parts in the reverse order of removal. Clips...

  • Page 130: Checking The Engine Oil

    Engine Oil Checking the Engine Oil NC750XA Upper level If the engine is cold, idle the engine for 3 to 5 minutes. Turn the ignition switch to the OFF position and wait for 2 to 3 minutes. Place your vehicle in an upright position Lower level on a firm, level surface.

  • Page 131: Adding Engine Oil

    Engine Oil Adding Engine Oil Adding Engine Oil Securely reinstall the oil fill cap/dipstick. NOTICE If the engine oil is below or near the lower Overfilling with oil or operating with insufficient level mark, add the recommended engine oil. oil can cause damage to your engine. Do not mix P.

  • Page 132: Checking The Coolant

    Coolant Checking the Coolant serious leak. Have your vehicle inspected by your dealer. Check the coolant level in the reserve tank Adding Coolant while the engine is cold. Place your vehicle on a firm, level surface. If the coolant level is below the LOWER level Hold your vehicle in an upright position.
  • Page 133 Coolant Adding Coolant Remove the reserve tank cap and add Reserve tank cap fluid while monitoring the coolant level. Do not overfill above the UPPER level mark. Make sure no foreign objects enter the reserve tank opening. Securely reinstall the reserve tank cap. Install the lower cowl.

  • Page 134: Brakes

    Brakes Checking Brake Fluid If the brake fluid level in either reservoir is below the LOWER level mark or the brake lever and pedal freeplay becomes excessive, Place your vehicle in an upright position inspect the brake pads for wear. on a firm, level surface.

  • Page 135: Inspecting The Brake Pads

    Brakes Inspecting the Brake Pads Inspecting the Brake Pads Inspect the brake pads from below Front the brake caliper. Inspect the brake pads from the rear Check the condition of the brake pad wear Rear right of the vehicle. indicators. If necessary, have the pads replaced by your The pads need to be replaced if a brake pad dealer.

  • Page 136: Checking The Parking Brake

    Brakes Checking the Parking Brake Checking the Parking Brake Adjusting the Brake Light Switch NC750XD Check the operation of the brake light switch. Parking brake lever Hold the brake light switch and turn the adjusting nut in the direction A if the switch operates too late, or turn the nut in the direction B if the switch operates too soon.

  • Page 137: Checking The Side Stand

    Side Stand Checking the Side Stand NC750XA Sit on the vehicle, shift the transmission to Neutral, and raise the side stand. NC750XD Sit on the vehicle and raise the side stand. NC750XA Start the engine, pull the clutch lever in, Side stand and shift the transmission into gear.

  • Page 138: Drive Chain

    Drive Chain Inspecting the Drive Chain Slack Drive chain Check the drive chain slack at several points along the chain. If the slack is not constant at all points, some links may be kinked and binding. Have the chain inspected by your dealer. Shift the transmission to Neutral.
  • Page 139 Drive Chain Checking the Drive Chain Slider Checking the Drive Chain Slider Check the condition of the drive chain slider. The drive chain slider will need to be replaced if the chain slider is worn to the wear limit line. If necessary, have the drive chain slider replaced by your dealer.

  • Page 140: Checking The Clutch

    Clutch Checking the Clutch Check the clutch cable for kinks or signs of wear. If necessary, have it replaced by your dealer. NC750XA Lubricate the clutch cable with a Checking the Clutch Lever Freeplay commercially available cable lubricant to prevent premature wear and corrosion. Check the clutch lever freeplay.

  • Page 141: Adjusting The Clutch Lever Free Play

    Clutch Adjusting the Clutch Lever Freeplay Adjusting the Clutch Lever Upper clutch cable adjuster Freeplay – NC750XA Upper Adjustment Attempt adjustment with the upper clutch cable adjuster first. Loosen the upper lock nut. Turn the upper clutch cable adjuster until the freeplay is 3/8 - 13/16 in (10 - 20 mm).
  • Page 142 Clutch Adjusting the Clutch Lever Freeplay Lower Adjustment and open the throttle. Your vehicle should move smoothly and accelerate gradually. If the upper clutch cable adjuster is threaded Lower lock nut out near its limit, or the correct freeplay cannot be obtained, attempt adjustment with the lower clutch cable adjusting nut.

  • Page 143: Throttle

    Throttle Checking the Throttle With the engine off, check that the throttle rotates smoothly from fully closed to fully open. If the throttle does not move smoothly or close automatically, have the vehicle inspected by your dealer. Throttle...

  • Page 144: Other Adjustments

    Other Adjustments Adjusting the Brake Lever Adjuster You can adjust the distance between the brake lever and handle grip. Index mark Adjustment method Forward Turn the adjuster until the numbers align with the index mark while pushing the lever forward in the desired position. After adjustment, check that the lever operates correctly before riding.

  • Page 145: Adjusting The Rear Suspension

    Other Adjustments Adjusting the Rear Suspension Adjusting the Rear Suspension Pin spanner 7 6 5 4 Adjusting the suspension requires a pin spanner. We recommend that you have your vehicle serviced by your dealer. Spring Preload You can adjust the spring preload by the Adjuster adjuster to suit the load or the road surface.

  • Page 146: Troubleshooting

    Troubleshooting Engine Will Not Start........P. 143 Electrical Trouble..........P. 152 Overheating (High coolant temperature Battery Goes Dead..........P. 152 indicator is on) ..........P. 144 Burned-out Light Bulb ........P. 152 Warning Indicators On or Flashing..... P. 145 Blown Fuse............P. 153 Low Oil Pressure Indicator ......

  • Page 147: Engine Will Not Start

    Engine Will Not Start Starter Motor Operates But Starter Motor Does Not Engine Does Not Start Operate Check the following items: Check the following items: Check the correct engine starting Check the correct engine starting ● ● sequence. P. 83 sequence.

  • Page 148: Overheating (High Coolant Temperature Indicator Is On)

    Overheating (High coolant temperature indicator is on) The engine is overheating when the following If the fan is not operating: occurs: Suspect a fault. Do not start the engine. High coolant temperature indicator Transport your vehicle to your dealer. ● comes on.

  • Page 149: Warning Indicators On Or Flashing

    Warning Indicators On or Flashing Low Oil Pressure Indicator If the engine oil level goes down rapidly, your vehicle may have a leak or another serious problem. Have your vehicle inspected by If the low oil pressure indicator comes on, your dealer.

  • Page 150: Pgm-Fi (Programmed Fuel Injection) Malfunction Indicator Lamp (Mil)

    Warning Indicators On or Flashing PGM-FI (Programmed Fuel Injection) Malfunction Indicator Lamp (MIL) PGM-FI (Programmed Fuel Injection) Malfunction Indicator Lamp (MIL) If the indicator comes on while riding, you may have a serious problem with the PGM-FI system. Reduce speed and have your vehicle inspected by your dealer as soon as possible.

  • Page 151: Abs (Anti-Lock Brake System) Indicator

    Warning Indicators On or Flashing ABS (Anti-lock Brake System) Indicator ABS (Anti-lock Brake System) If the ABS indicator stays on, your brakes will continue to work as a conventional system, Indicator but without the anti-locking function. If the indicator operates in one of the The ABS indicator may flash if you turn the following ways, you may have a serious rear wheel while the rear wheel is lifted off...

  • Page 152: Torque Control Indicator

    Warning Indicators On or Flashing Torque Control Indicator Torque Control Indicator Even when the Torque Control indicator is on, your vehicle will have normal riding ability without Torque Control function. If the indicator operates in one of the When the indicator comes on while the following ways, you may have a serious Torque Control is in operation, you will problem with the Torque Control.

  • Page 153: If The "-" Indicator Is Blinking In The Gear Position Window While Riding

    If the “–” Indicator is Blinking in the Gear Position Window While Riding NC750XD If you still cannot start the engine: If the “–” indicator is blinking while riding, you Start the engine while applying the brake may have a serious problem with the Dual lever or pressing the brake pedal.

  • Page 154: Other Warning Indications

    Other Warning Indications Fuel Gauge Failure Indication If the fuel system has an error, the fuel gauge indicators will be displayed as shown in the illustration. If this occurs, see your dealer as soon as possible.

  • Page 155: Tire Puncture

    Tire Puncture WARNING Repairing a puncture or removing a wheel requires special tools and technical expertise. Riding your vehicle with a temporary We recommend you have this type of service tire repair can be risky. If the temporary performed by your dealer. repair fails, you can crash and be After an emergency repair, always have the seriously injured or killed.

  • Page 156: Electrical Trouble

    Electrical Trouble Battery Goes Dead Burned-out Light Bulb Charge the battery using a motorcycle All light bulbs on the vehicle are LEDs. If battery charger. there is an LED which is not turned on, see Remove the battery from the vehicle before your dealer for servicing.

  • Page 157: Blown Fuse

    Electrical Trouble Blown Fuse Blown Fuse NC750XA Before handling fuses, see “Inspecting and Replacing Fuses.” P. 111 Fuse box cover Fuse Box Fuses Open the luggage box. P. 96 Remove the maintenance lid. P. 125 Remove the fuse box cover. Spare fuses Pull the fuses out one by one with the fuse puller in the tool kit and check for a...
  • Page 158 Electrical Trouble Blown Fuse Main Fuse Disconnect the wire connector of the starter magnetic switch. Wire connector Pull the main fuse out and check for a blown fuse. Always replace a blown fuse with a spare fuse of the same rating. Main fuse Spare main fuse is provided in the starter magnetic switch.

  • Page 159: Information

    Vehicle Identification Number..... P. 166 Emission Control Systems ......P. 167 Catalytic Converter ......... P. 171 Oxygenated Fuels..........P. 172 Authorized Manuals ........P. 173 Warranty Coverage and Service ....P. 174 Honda Contacts ..........P. 177 Reporting Safety Defects ......P. 179...

  • Page 160: Keys

    Keys Keys Ignition key Key tag Ignition Key This vehicle has two ignition keys and a key tag with a key number and a bar code. Store the spare key and the key tag in a safe location. To make a duplicate key, take the spare key and the key tag to your dealer or a locksmith.

  • Page 161: Instruments, Controls, & Other Features

    Instruments, Controls, & Other Features Instruments, Controls, & Odometer Other Features The display remains at 999,999 when the odometer exceeds 999,999. Ignition Switch Tripmeter Leaving the ignition switch in the ON position Each tripmeter resets to 0.0 when the trip with the engine stopped will drain the battery.

  • Page 162: Caring For Your Vehicle

    NC750XA Frequent cleaning and polishing is important to The assist-slipper clutch system helps to prevent ensure the life of your Honda. A clean vehicle the rear tire from locking up when the makes it easier to spot potential problems. deceleration of your vehicle produces a strong In particular, seawater and salts used to prevent engine braking effect.
  • Page 163 Caring for Your Vehicle If necessary, use a sponge or a soft towel Apply a coat of wax to prevent corrosion. with mild cleaner to remove road grime. Avoid products that contain harsh Clean the windscreen, headlight lens, detergents or chemical solvents. These panels, and other plastic components can damage the metal, paint, and plastic with extra care to avoid scratching them.
  • Page 164 Caring for Your Vehicle Dry the brakes: Do not use wax or polishing compounds on ● ● Water adversely affects braking matte painted surfaces: effectiveness. After washing, apply the Use a soft cloth or sponge, plenty of brakes intermittently at low speed to water, and a mild detergent to clean help dry them.
  • Page 165 Caring for Your Vehicle Panels Windscreen Follow these guidelines to prevent scratches Using plenty of water, clean the windscreen with and blemishes: a soft cloth or sponge. (Avoid using detergents Wash gently using a soft sponge and plenty or any kind of chemical cleaner on the ●...
  • Page 166 Caring for Your Vehicle If the exhaust pipe and muffler are painted, do Exhaust Pipe and Muffler not use a commercially available abrasive The exhaust pipe and muffler are stainless steel kitchen cleaning compound. Use a neutral but may become stained by mud or dust. detergent to clean the painted surface on the exhaust pipe and muffler.

  • Page 167: Storing Your Vehicle

    After rain, remove the body cover and allow ● the vehicle to dry. For more information about storage, Canada visit our website at www.honda.ca and look up “Storage Tips” under the “Honda Warranty” in the Warranty tab for your Model.

  • Page 168: Transporting Your Vehicle

    Transporting Your Vehicle Transporting Your Vehicle You & the Environment If your vehicle needs to be transported, it Owning and riding a vehicle can be enjoyable, should be carried on a motorcycle trailer or a but you must do your part to protect the flatbed truck or trailer that has a loading ramp environment.
  • Page 169 You & the Environment Recycle Wastes Put oil and other toxic wastes in approved containers and take them to a recycling center. Call your local or state office of public works or environmental services to find a recycling center in your area and to get instructions on how to dispose of non-recyclable wastes.

  • Page 170: Vehicle Identification Number

    Vehicle Identification Number Vehicle Identification Number The VIN and engine serial number uniquely identify your vehicle and are required in order to register your vehicle. They may also be required when ordering replacement parts. You should record these numbers and keep them in a safe place.

  • Page 171: Emission Control Systems

    Your vehicle engine emits combustion Compliance with the terms of the byproducts, including carbon monoxide (CO), Distributor's Warranties for Honda Motorcycle oxides of nitrogen (NOx), and hydrocarbons Emission Control Systems is necessary in order (HC). Gasoline evaporation also emits to maintain a valid emissions system warranty.
  • Page 172 Emission Control Systems Ignition Timing Control System Noise Emission Requirements The ignition timing control system adjusts the The EPA requires that vehicles built after ignition timing to reduce the amount of HC, January 1, 1983 comply with applicable noise CO, and NOx produced. emission standards for one year or 3,730 miles (6,000 km) after the time of purchase when Catalytic Converters...
  • Page 173 Emission Control Systems Crankcase Emissions Control System Noise Emission Control System The engine is equipped with a closed crankcase TAMPERING WITH THE NOISE CONTROL system to prevent discharging crankcase SYSTEM IS PROHIBITED: emissions into the atmosphere. U. S. federal law prohibits, and Canadian Blow-by gas is returned to the combustion provincial laws may prohibit, the following acts chamber through the air cleaner and throttle...
  • Page 174 Emission Control Systems AMONG THOSE ACTS PRESUMED TO Problems Affecting Vehicle Exhaust CONSTITUTE TAMPERING ARE THE Emissions FOLLOWING ACTS: Have your vehicle inspected and repaired by Removal of, or puncturing the muffler, ● your dealer if you experience any of the baffles, header pipes or any other following symptoms: component which conducts exhaust gases.

  • Page 175: Catalytic Converter

    A defective catalytic converter contributes to air or otherwise not running properly, stop pollution and can impair your engine's riding and turn off the engine. Have your performance. A replacement unit must be an vehicle serviced as soon as possible. original Honda part or equivalent.

  • Page 176: Oxygenated Fuels

    Oxygenated Fuels Oxygenated Fuels If you accidentally fill your fuel tank with an oxygenated fuel containing higher percentages, Some conventional fuels blended with alcohol you may experience performance problems. To or an ether compound are available in some resolve the problem, have your dealer drain the locales to help reduce emissions to meet clean fuel tank and replace with the correct fuel.

  • Page 177: Authorized Manuals

    Authorized Manuals Authorized Manuals These Honda manuals are written for the professional technician. However, if you possess The Service Manual used by your the proper tools, observe the safety standards, authorized dealer is available from your Honda and are mechanically capable, you should find dealer or Helm, Inc.

  • Page 178: Warranty Coverage And Service

    Service workmanship of your Honda. Your warranty coverage does not apply to the normal wear Coverage and deterioration associated with use of the Your new Honda is covered by the following vehicle. warranties: Vehicle Limited Warranty ● Your warranty coverage is not voided if you Emission Control System Warranty ●...
  • Page 179 Warranty Coverage and Service authorized service provider caused damage to Statement on Warranty Coverage for another part of the vehicle otherwise covered Aftermarket and Recycled Parts under warranty before denying warranty The Magnuson-Moss Warranty Act, 15 U.S.C. s. coverage. Additionally, federal law allows a 2301 et seq., makes it illegal for motor vehicle manufacturer to void a motor vehicle warranty manufacturers to void a motor vehicle warranty...
  • Page 180 If you believe you have a problem with your dealership or their designated representative. vehicle, call the service department of your Honda dealer. Make an appointment for an inspection and diagnosis. You will be asked to authorize that inspection, and your dealer will return the results of the inspection.

  • Page 181: Honda Contacts

    Alpharetta, GA 30005-8847 Product model, year, and VIN ● Date of purchase ● Dealer name and address ● Telephone: (866) 784-1870 We will likely ask your Honda dealer to respond, or possibly acknowledge your comments Website: https://powersports.honda.com/ directly. contact-us Continued...
  • Page 182 Your Honda Dealer HondaCare Protection Plan to extend almost ® The service department of your Honda dealer all of your warranty coverage. offers trained personnel to perform regular maintenance and unexpected repairs. It has the Your Honda dealer can also supply information...

  • Page 183: Reporting Safety Defects

    Reporting Safety Defects Reporting Safety Defects dealer, or American Honda Motor Co., Inc. If you believe that your vehicle has a To contact NHTSA, you may call the defect which could cause a crash or Vehicle Safety Hotline toll-free at:...
  • Page 184 (English Link:) www.tc.canada.ca/recalls remedy campaign. However, Transport (French Link:) www.tc.canada.ca/rappels Canada cannot become involved in individual problems between you, your For more information on reporting safety defects or about motor vehicle dealer, or Honda Canada Inc. safety, go to https://www.tc.gc.ca/roadsafety.

  • Page 185: Specifications

    Specifications Main Components ■ YTZ12S Battery Overall length 87.0 in (2,210 mm) 12 V-11.0 Ah (10 HR) Overall width 33.3 in (846 mm) 2.666 Overall height 52.4 in (1,330 mm) 1.904 NC750XA 60.0 in (1,525 mm) 1.454 Wheelbase Gear ratio NC750XD 60.4 in (1,535 mm) 1.178...
  • Page 186 API service label, Recommended SAE 10W-30, JASO T 903 standard MA, Pro engine oil Honda GN4 4-stroke oil (USA & Canada) or Honda 4-stroke oil, or an equivalent motorcycle oil...
  • Page 187 Recommended Pro Honda HP Coolant coolant Headlight Recommended Brake light/Taillight drive chain Pro Honda HP Chain Lube or equivalent Front turn signal lubricant Rear turn signal Drive chain slack 1 - 1 3/8 in (25 - 35 mm) Position light...
  • Page 188 Information Record Engine No. Color Label & Code Owner's Name Address City/State Phone Dealer's Name Address City/State Phone Service Manager...
  • Page 189 California Proposition 65 Warning WARNING: Operating, servicing and maintaining a passenger vehicle or off-highway motor vehicle can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm.
  • Page 190 31MKW830 © 2023 Honda Motor Co., Ltd. 00X31-MKW-8300 Printed in the U.S.A. All Rights Reserved...

Table of Contents
