The MSTP Debug Enhancement commands in the Command Line Interface (CLI) are listed (along with the appropriate
parameters) in the following table.
Command
debug buffer
debug output
debug stp config ports
debug stp show information
debug stp show flag
debug stp show counter
debug stp clear counter
debug stp state
Each command is listed, in detail, in the following sections.
debug buffer
Purpose
Syntax
Description
Parameters
Restrictions
Example usage:
To clear the debug information in the buffer:
DGS-3627:admin# debug buffer clear
Command: debug buffer clear
Success.
DGS-3627:admin#
®
DGS-3600 Series Layer 3 Gigabit Ethernet Managed Switch CLI Manual

MSTP DEBUG ENHANCEMENT COMMANDS

Parameters
utilization | dump | clear | upload_toTFTP <ipaddr> <path_filename 64>]
module mstp [buffer | console]
[ < portlist > | all ] [ event | bpdu | state_machine | all ] state [ disable | brief |
detail ]
{ports <portlist>}
{ports [<portlist> | all]}
[ports < portlist > | all ]
[enable | disable]
Use the debug buffer command to dump, clear, or upload the debug buffer to the TFTP
server.
debug buffer [utilization | dump | clear | upload_toTFTP <ipaddr> <path_filename 64>]
Dump, clear or upload the debug buffer to a TFTP server.
dump - Displays the debug message in the debug message buffer.
clear - Clears the debug message buffer.
upload_toTFTP <ipaddr> - Uploads the debug message buffer to a TFTP server with a
specified IP address
<path_filename 64> - Upload the debug message buffer to a TFTP server and name the
uploaded file using the string identified in the <path_filename 64> option.
Only Administrator and Operator-level users can issue this command.
