xStack
DGS-3627:admin# disable sim
Command: disable sim
Success.
DGS-3627:admin#
show sim
Purpose
Syntax
Description
Parameters
Restrictions
Example usage:
To show the SIM information in detail:
®
DGS-3600 Series Layer 3 Gigabit Ethernet Managed Switch CLI Manual
Used to view the current information regarding the SIM group on the Switch.
show sim {[candidates {<candidate_id 1-100>} | members {<member_id 1-32>} | group
{commander_mac <macaddr>} | neighbor]}
This command will display the current information regarding the SIM group on the Switch,
including the following:
SIM Version – Displays the current Single IP Management version on the Switch.
Firmware Version – Displays the current Firmware version on the Switch.
Device Name – Displays the user-defined device name on the Switch.
MAC Address – Displays the MAC Address of the Switch.
Capabilities – Displays the type of switch, be it Layer 2 (L2) or Layer 3 (L3).
Platform – Switch Description including name and model number.
SIM State –Displays the current Single IP Management State of the Switch, whether it be
enabled or disabled.
Role State – Displays the current role the Switch is taking, including Commander, Member or
Candidate. A Stand-alone switch will always have the commander role.
Discovery Interval – Time in seconds the Switch will send discovery packets out over the
network.
Hold time – Displays the time in seconds the Switch will hold discovery results before dropping
it or utilizing it.
candidates <candidate_id 1-100> – Entering this parameter will display information concerning
candidates of the SIM group. To view a specific candidate, include that candidate's ID number,
listed from 1 to 100.
members <member_id 1-32> – Entering this parameter will display information concerning
members of the SIM group. To view a specific member, include that member's id number,
listed from 1 to 32.
group {commander_mac <macaddr>} – Entering this parameter will display information
concerning the SIM group. To view a specific group, include the commander's MAC address of
the group.
neighbor – Entering this parameter will display neighboring devices of the Switch. A SIM
neighbor is defined as a switch that is physically connected to the Switch but is not part of the
SIM group. This screen will produce the following results:
•
Port – Displays the physical port number of the commander switch where the uplink
to the neighbor switch is located.
•
MAC Address – Displays the MAC Address of the neighbor switch.
•
Role – Displays the role(CS, CaS, MS) of the neighbor switch.
Only Administrator and Operator-level users can issue this command.
244
