THE BIS-10 VOICE
TERMINAL USED AS AN
ADMINISTRATOR
CONSOLE
ADMINISTRATION MODE
For example, if you want to assign voice terminal 21 to a Group Page group or
add the voice terminal to an Allowed List, use the dial code, #04, that
corresponds with intercom number 21.
It is important that you record your decisions about Allowed and
NOTE:
Disallowed Lists on the Call Restrictions Assignment Form; record
decisions about your Call Report and/or System Feature Report jack
assignment and Group Page on the System Configuration Form.
Keep these forms handy in case you decide to make changes.
The BIS-10 voice terminal is not recommended to be used as the
administrator/attendant console because the administrator cannot see the buttons
being administered. Furthemore, some features cannot be programmed from
this voice terminal. However, if you are using a BIS-10 voice terminal as an
administrator/attendant console to perform the administration procedures for
many of the special features, follow the instructions provided for the BIS-22
voice terminal, which generally require that you enter the dial codes
(see chart below) directly without touching an Auto Intercom button.
If the intercom
number is:
Intercom 10
Intercom 11
Intercom 12
Intercom 13
Intercom 14
Intercom 15
Intercom 16
Intercom 17
Intercom 18
Intercom 19
The information under the next three headings tells you how to do the following:
Make button label sheets for the administrator/attendant console
Enter administration mode
Leave administration mode
Labeling Buttons
The button label sheets on your administrator/attendant console have to show
how the functions of certain buttons change when you shift from the normal
call-handling mode to the administration mode. Figure 3-2 shows you what the
button labels should look like for a BIS-34D voice terminal with Display. Figure
3-3 shows the button labels for a BIS-22 voice terminal.
If the intercom
Dial this code: number is:
#22 Intercom 20
#21 intercom 21
#20 Intercom 22
#19 Intercom 23
#18
Intercom 24
#17
Intercom 25
#16
Intercom 26
#15
Intercom 27
#14
Intercom 28
#13 Intercom 29
Dial this code:
#03
#04
#05
#06
#07
#08
#09
#l0
#11
#12
Administration Preview 3-7
