2 Models and External Dimensions
3-phase 200 VAC: R88D-1SN55H-ECT/ -1SN75H-ECT (5.5 to 7.5 kW)
3-phase 400 VAC: R88D-1SN55F-ECT/ -1SN75F-ECT (5.5 to 7.5 kW)
External Mounting dimensions
dimensions
200 50 235
2
M5
4-M5
Air outlet
Air
160±0.5
20
intake
200
2-M5
Shield Clamp
46
2 - 40
