Parameters
7.2 Parameter list
p1051[0...n]

CI: Speed limit RFG positive direction of rotation / n_limit RFG pos

Access level: 3
Can be changed: T
Unit group: -
Min:
-
Description: Sets the signal source for the speed limit of the positive direction on the ramp-function generator input.
Note
The OFF3 ramp-down time (p1135) is effective when the limit is reduced.
p1052[0...n]

CI: Speed limit RFG negative direction of rotation / n_limit RFG neg

Access level: 3
Can be changed: T
Unit group: -
Min:
-
Description: Sets the signal source for the speed limit of the negative direction on the ramp-function generator input.
Note
The OFF3 ramp-down time (p1135) is effective when the limit is reduced.
p1055[0...n] BI: Jog bit 0 / Jog bit 0
G120X_DP, Access level: 3
G120X_PN
Can be changed: T
Unit group: -
Min:
-
Description: Sets the signal source for jog 1.
Recommendation: When the setting for this binector input is changed, the motor can only be switched on by means of an appropriate
signal change of the source.
Dependency: See also: p0840, p1058
NOTICE
The drive is enabled for jogging using BI: p1055 or BI: p1056.
The command "ON/OFF1" can be issued using BI: p0840 or using BI: p1055/p1056.
Only the signal source that was used to switch on can also be used to switch off again.
p1055[0...n] BI: Jog bit 0 / Jog bit 0
G120X_USS Access level: 3
Can be changed: T
Unit group: -
Min:
-
Description: Sets the signal source for jog 1.
Recommendation: When the setting for this binector input is changed, the motor can only be switched on by means of an appropriate
signal change of the source.
620
Calculated: -
Scaling: p2000
Unit selection: -
Max:
-
Calculated: -
Scaling: p2000
Unit selection: -
Max:
-
Calculated: -
Scaling: -
Unit selection: -
Max:
-
Calculated: -
Scaling: -
Unit selection: -
Max:
-
Operating Instructions, 06/2019, FW V1.01, A5E44751209B AC
Data type: Unsigned32 /
FloatingPoint32
Dynamic index: CDS, p0170
Function diagram: 3050
Factory setting:
1083[0]
Data type: Unsigned32 /
FloatingPoint32
Dynamic index: CDS, p0170
Function diagram: 3050
Factory setting:
1086[0]
Data type: Unsigned32 / Binary
Dynamic index: CDS, p0170
Function diagram: 2501, 3030
Factory setting:
[0] 0
[1] 722.0
[2] 0
[3] 0
Data type: Unsigned32 / Binary
Dynamic index: CDS, p0170
Function diagram: 2501, 3030
Factory setting:
0
SINAMICS G120X converter
