Parameters
7.2 Parameter list
p1269[0...1]

BI: Bypass switch feedback signal / Bypass FS

Access level: 3
Can be changed: T, U
Unit group: -
Min:
-
Description: Sets the signal source for the feedback signal of the bypass switch.
Index: [0] = Switch motor/drive
[1] = Switch motor/line supply
Dependency: The "Bypass" function is only available for induction motors.
Note
In the case of switches without a feedback signal, interconnect the corresponding control bit as the signal source:
BI: p1269[0] = r1261.0
BI: p1269[1] = r1261.1
Entering p1269 = 0 sets this interconnection automatically for switches without a feedback signal.
p1270[0...n]

Flying restart configuration / Fly restart config

G120X_DP (PM330), Access level: 4
G120X_PN (PM330),
Can be changed: T, U
G120X_USS (PM330)
Unit group: -
Min:
-
Description: Sets the configuration for the "flying restart function" function.
Bit field: Bit
00
01
12
13
14
15
Note
ASM: Induction motor
For bit 00:
This bit is equivalent to p1780 bit 11.
For bit 01:
This bit should only be set when required for large drives.
p1271[0...n] Flying restart maximum frequency for the inhibited direction / FlyRes f_max dir
Access level: 3
Can be changed: T, U
Unit group: -
Min:
0 [Hz]
Description: Sets the maximum search frequency for a flying restart in an inhibited setpoint direction (p1110, p1111).
Note
The parameter has no effect for an operating mode, which only searches in the setpoint direction (p1200 > 3).
662
Signal name
Fast flying restart with voltage model for induction motor
PLL expansion for fast flying restart w/ voltage model for ASM Yes
Use peak current values
Number of current controller cycles (test pulse) bit 0
Number of current controller cycles (test pulse) bit 1
Number of current controller cycles (test pulse) bit 2
Calculated: -
Scaling: -
Unit selection: -
Max:
-
Calculated: -
Scaling: -
Unit selection: -
Max:
-
1 signal
Yes
Yes
1
1
1
Calculated: -
Scaling: -
Unit selection: -
Max:
650 [Hz]
Operating Instructions, 06/2019, FW V1.01, A5E44751209B AC
Data type: Unsigned32 / Binary
Dynamic index: -
Function diagram: -
Factory setting:
[0] 1261.0
[1] 1261.1
Data type: Unsigned16
Dynamic index: DDS, p0180
Function diagram: -
Factory setting:
0000 0000 0000 0011 bin
0 signal FP
No -
No -
No -
0 -
0 -
0 -
Data type: FloatingPoint32
Dynamic index: DDS, p0180
Function diagram: -
Factory setting:
0 [Hz]
SINAMICS G120X converter
