Advanced commissioning
6.3 Drive control
No.
6
7
Table 6-21
Byte Bit
1
2
Assembly Object, Instance Number: 4 hex
Supported services
Class
Table 6-22
No.
1
2
3
228
Service Type Name
get UINT32 Serial number
get Short Product name
String

Explanation of No. 5 of the previous table

Name
0 Owned
1
2 Configured
3
4 ... 7 Extended De‐
vice Status
8 ... 11
12 ... 15
● Get Attribute single

Class Attribute

Service Type
get UINT16
get UINT16
get UINT16
Value/explanation
bits 0 ... 19: consecutive number;
bits 20 ... 23: Production identifier
bits 24 ... 27: Month of manufacture (0 = Jan, B =
Dec)
Bits 28 ... 31: Year of manufacture (0 = 2002)
Max. length 32 bytes
Description
0: Converter is not assigned to any master
1: Converter is assigned to a master
Reserved
0: Ethernet/IP basic settings
1: Modified Ethernet/IP settings
For G120, always = 1
Reserved
0: Self-test or status not known
1: Firmware update active
2: At least one I/O connection with error
3: No I/O connections
4: Incorrect configuration in the ROM
5: Fatal fault
6: At least one I/O connection is active
7: All I/O connections in the quiescent state
8 ... 15: Reserved
Not used
Reserved
Instance
Name
Revision
Max Instance
Num of Instances
Operating Instructions, 06/2019, FW V1.01, A5E44751209B AC
● Get Attribute single
● Set Attribute single
SINAMICS G120X converter
