Parameter Object,
Supported services
Class
Table 6-40
No.
1
2
3
Cyclic communication is established via parameter object 401.
Example: Read parameter 2050[10] (connector output to interconnect the PZD received from
the fieldbus controller)
Get Attribute single function with the following values:
● Class = 401 hex
● Instance = 2050 = 802 hex corresponds to the parameter number
● Attribute = 10 = A hex corresponds to index 10
Example: Parameter 1520[0] writing (upper torque limit)
Set Attribute single function with the following values:
● Class = 401 hex
● Instance = 1520 = 5F0 hex corresponds to the parameter number
● Attribute = 0 = 0 hex corresponds to index 0
● Data = 500.0 (value)

Supported ODVA AC/DC assemblies

Overview
Number required/
optional
hex dec
14 hex 20 Required
46 hex 70 Required
SINAMICS G120X converter
Operating Instructions, 06/2019, FW V1.01, A5E44751209B AC

Instance Number: 401 hex

● Get Attribute all
Class Attribute
Service Type
get UINT16
get UINT16
get UINT16
Type
Sending
Receiving
Instance
Name
Revision
Max Instance
Num of Instances
Name
Basic Speed Control Output
Basic Speed Control Input
Advanced commissioning
6.3 Drive control
● Get Attribute all
● Set Attribute single
239
