Parameters
7.2 Parameter list
00
01
02
03
04
05
06
09
10
Note
ESM: Essential Service Mode
p3900
Completion of quick commissioning / Compl quick_comm
Access level: 1
Can be changed: C2(1)
Unit group: -
Min:
0
Description:
Exits quick commissioning (p0010 = 1) with automatic calculation of all parameters of all existing drive data sets that
depend on the entries made during quick commissioning.
p3900 = 1 initially includes a parameter reset (factory setting, the same as p0970 = 1) for all parameters of the drive
object; however, without overwriting the entries made during the quick commissioning.
The interconnections of PROFIBUS PZD telegram selection (p0922) and the interconnections via p15 and p1500 are
re-established and all of the dependent motor, open-loop and control-loop control parameters are calculated
(corresponding to p0340 = 1).
p3900 = 2 includes the restoration of the interconnections of PROFIBUS PZD telegram selection (p0922) and the
interconnections via p15 and p1500 and the calculations corresponding to p0340 = 1.
p3900 = 3 only includes the calculations associated with the motor, open-loop and closed-loop control parameters
corresponding to p0340 = 1.
Value:
0:
1:
2:
3:
NOTICE
After the value has been modified, no further parameter modifications can be made and the status is shown in r3996.
Modifications can be made again when r3996 = 0.
Note
When the calculations have been completed, p3900 and p0010 are automatically reset to a value of zero.
When calculating motor, open-loop and closed-loop control parameters (such as for p0340 = 1) parameters associated
with a selected Siemens catalog motor are not overwritten.
If a catalog motor has not been selected (p0300), then the following parameters are reset with p3900 > 0 in order to
restore the situation that applied when commissioning the drive for the first time:
induction motor: p0320, p0352, p0362 ... p0369, p0604, p0605, p0626 ... p0628
synchronous motor: p0326, p0327, p0352, p0604, p0605
r3925[0...n]
Identification final display / Ident final_disp
Access level: 3
Can be changed: -
Unit group: -
Min:
-
846
Essential service mode (ESM) activated
Direction of rotation inverted
Setpoint signal lost
Technology controller actual value (p2264) lost
Bypass active
Setpoint technology controller parameterized (p3884)
Technology controller during essential service mode active Yes
Response OFF1/OFF2 activated
Automatic restart interrupted (F07320)
No quick parameterization
Quick parameterization after parameter reset
Quick parameterization (only) for BICO and motor parameters
Quick parameterization for motor parameters (only)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Calculated: -
Scaling: -
Unit selection: -
Max:
3
Calculated: CALC_MOD_ALL Data type: Unsigned32
Scaling: -
Unit selection: -
Max:
-
Operating Instructions, 06/2019, FW V1.01, A5E44751209B AC
No
-
No
-
No
-
No
-
No
-
No
-
No
-
No
-
No
-
Data type: Integer16
Dynamic index: -
Function diagram: -
Factory setting:
0
Dynamic index: DDS, p0180
Function diagram: -
Factory setting:
-
SINAMICS G120X converter
