Parameters
7.2 Parameter list
p2223[0...n] BI: Technology controller fixed value selection bit 3 / Tec_ctrl sel bit 3
Access level: 3
Can be changed: T
Unit group: -
Min:
-
Description: Sets the signal source to select a fixed value of the technology controller.
Dependency: See also: p2220, p2221, p2222
r2224 CO: Technology controller fixed value effective / Tec_ctr FixVal eff
Access level: 3
Can be changed: -
Unit group: 9_1
Min:
- [%]
Description: Display and connector output for the selected and active fixed value of the technology controller.
Dependency: See also: r2229
r2225.0 CO/BO: Technology controller fixed value selection status word / Tec_ctr FixVal ZSW
Access level: 3
Can be changed: -
Unit group: -
Min:
-
Description: Display and BICO output for the status word of the fixed value selection of the technology controller.
Bit field: Bit
00
r2229 Technology controller number actual / Tec_ctrl No. act
Access level: 3
Can be changed: -
Unit group: -
Min:
-
Description: Displays the number of the selected fixed setpoint of the technology controller.
Dependency: See also: r2224
p2230[0...n] Technology controller motorized potentiometer configuration / Tec_ctr mop config
Access level: 3
Can be changed: T, U
Unit group: -
Min:
-
Description: Sets the configuration for the motorized potentiometer of the technology controller.
Bit field: Bit
00
02
03
796
Signal name
Technology controller fixed value selected
Signal name
Data save active
Initial rounding-off active
Non-volatile data save active for p2230.0 = 1
Calculated: -
Scaling: -
Unit selection: -
Max:
-
Calculated: -
Scaling: PERCENT
Unit selection: p0595
Max:
- [%]
Calculated: -
Scaling: -
Unit selection: -
Max:
-
1 signal
Yes
Calculated: -
Scaling: -
Unit selection: -
Max:
-
Calculated: -
Scaling: -
Unit selection: -
Max:
-
1 signal
Yes
Yes
Yes
Operating Instructions, 06/2019, FW V1.01, A5E44751209B AC
Data type: Unsigned32 / Binary
Dynamic index: CDS, p0170
Function diagram: 7950, 7951
Factory setting:
0
Data type: FloatingPoint32
Dynamic index: -
Function diagram: 7950, 7951
Factory setting:
- [%]
Data type: Unsigned16
Dynamic index: -
Function diagram: -
Factory setting:
-
0 signal FP
No 7950,
7951
Data type: Unsigned32
Dynamic index: -
Function diagram: 7950
Factory setting:
-
Data type: Unsigned32
Dynamic index: DDS, p0180
Function diagram: 7954
Factory setting:
0000 0100 bin
0 signal FP
No -
No -
No -
