7. MAIN SHAFT ASSEMBLY
(2)
(15)
(14)
(1)
Main shaft
(2)
Needle bearing
(3)
3rd drive gear
(4)
Inner baulk ring
(5)
Synchro cone
(6)
Outer baulk ring
(7)
3rd-4th sleeve
(8)
3rd-4th hub
(9)
Shifting insert key
(10)
4th baulk ring
(11)
4th gear
General Description
(1)
(6)
(5)
(4)
(3)
(20)
(19)
(18)
(17)
(16)
(12)
4th bushing
(13)
Needle bearing
(14)
5th bushing
(15)
Needle bearing
(16)
5th drive gear
(17)
5th baulk ring
(18)
5th-6th sleeve
(19)
5th-6th hub
(20)
Shifting insert key
(21)
6th baulk ring
(22)
6th drive gear
MANUAL TRANSMISSION AND DIFFERENTIAL
(9)
(10)
(8)
(7)
(22)
(21)
(23)
6MT-9
(13)
(12)
(11)
(27)
(26)
(25)
(24)
(23)
Needle bearing
(24)
6th bushing
(25)
Taper roller bearing
(26)
Snap ring
(27)
Washer
(28)
Washer
(29)
Lock nut
⋅
Tightening torque: N
m (kgf-m, ft-lb)
T: 392 (40, 289.1)
(29)
(28)
MT-00442
