Programming Guide | VLT® AutomationDrive FC 360
Table 14: Preset Referenece Bits (continued)
Preset ref. bit
Preset ref. 6
Preset ref. 7
3-11 Jog Speed [Hz]
Default value:
5.0 Hz
Setup:
All setups
Data type:
Uint16
The jog speed is a fixed output speed at which the drive runs when the jog function is activated. See also parameter 3-80 Jog Ramp Time.
The jog speed must not exceed the setting in parameter 4-14 Motor Speed High Limit [Hz].
3-12 Catch Up/Slow Down Value
Default value:
0.00%
Setup:
All setups
Data type:
Int16
Enter a percentage value to be either added to or deducted from the actual reference for catching up or slowing down respectively. If
[28] Catch up is selected via 1 of the digital inputs (parameter 5-10 Terminal 18 Digital Input to parameter 5-15 Terminal 33 Digital Input),
the percentage value is added to the total reference. If [29] Slow down is selected via 1 of the digital inputs (parameter 5-10 Terminal 18
Digital Input to parameter 5-15 Terminal 33 Digital Input), the percentage value is deducted from the total reference.
3-13 Reference Site
Default value:
[0] Linked to Hand/Auto
Setup:
All setups
Data type:
Uint8
Select which reference site to activate.
Option
[0]
[1]
[2]
3-14 Preset Relative Reference
Default value:
0.00%
Setup:
All setups
Data type:
Int16
Danfoss A/S © 2024.01
2
1
1
Name
Linked to Hand/Auto
Remote
Local
1
1
1
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Description
Use the local reference in hand-on mode
or the remote reference in Auto mode.
Use the reference in hand-on mode.
Use the reference in Auto mode.
Parameter type:
Conversion index:
Change during operation:
AU275649936274en-001401 / 130R0507 |
0
0
1
Range (0.0–500.0 Hz)
-1
True
Range (0.00–100.00%)
-2
True
Option
–
True
Range (-100.00–100.00%)
0
True
