Programming Guide | VLT® AutomationDrive FC 360
Table 25: Warnings and Alarms Code List (continued)
Number Description
16 Short circuit
17 Control word timeout
18 Start failed
20 Temp. input error
22 Hoist mech. brake
25 Brake resistor short-cir-
cuited
26 Brake overload
27 Brake IGBT/Brake chop-
per short-circuited
28 Brake check
30 U phase loss
31 V phase loss
32 W phase loss
34 Fieldbus fault
35 Option fault
36 Mains failure
38 Internal fault
40 Overload T27
41 Overload T29
46 Gate drive voltage fault
47 24 V supply low
49 Speed Limit
50 AMA calibration
51 AMA check U
nom
I
nom
Danfoss A/S © 2024.01
Warning Alarm
– X
X X
– X
X X
X X
– X
X X
– X
– X
– X
– X
– X
X X
– X
X X
– X
X –
X –
– X
X X
X X
– X
and – X
Trip lock Cause
X Short circuit in motor or on motor terminals. For J7 units,
if this alarm occurs on power-up, check whether power
cables are mistakenly connected to the motor terminals.
– No communication to the drive.
– –
– The temperature detected by VLT® Sensor Input Option
MCB 114 exceeds the limit.
– The torque reference was not reached before timeout.
X Brake resistor is short-circuited, thus the brake function is
disconnected.
– The power transmitted to the brake resistor over the last
120 s exceeds the limit. Possible corrections: Decrease
brake energy via lower speed or longer ramp time.
X Brake transistor is short-circuited, thus brake function is
disconnected.
– Brake resistor is not connected/working.
X Motor phase U is missing. Check the phase.
X Motor phase V is missing. Check the phase.
X Motor phase W is missing. Check the phase.
– PROFIBUS communication issues have occurred.
– Fieldbus or option B detects internal faults.
– This warning/alarm is only active if the supply voltage
to the drive is lost and parameter 14-10 Mains Failure is
NOT set to [0] No Function.
X Contact the local supplier.
– Check the load connected to terminal 27 or remove
short circuit connection.
– Check the load connected to terminal 29 or remove
short circuit connection.
X –
X 24 V DC may be overloaded.
– The speed is outside of the specified range in parameter
4-12 Motor Speed Low Limit [Hz] and parameter 4-14
Motor Speed High Limit [Hz].
– –
– Wrong setting for motor voltage and/or motor current.
