Programming Guide | VLT® AutomationDrive FC 360
Setup:
All setups
Data type:
Uint32
This parameter holds the state of the bus-controlled digital outputs and relays. A logical 1 indicates that the output is high or active. A
logical 0 indicates that the output is low or inactive.
Table 18: Bit Functions
Bit 0
Bit 1
Bit 2–3
Bit 4
Bit 6–23
Bit 24
Bit 26–31
5-93 Pulse Out 27 Bus Control
Default value:
0.00%
Setup:
All setups
Data type:
Uint16
Set the output frequency transferred to the output terminal 27 when the terminal is configured as [45] Bus Controlled in parameter 5-60
Terminal 27 Pulse Output Variable.
5-94 Pulse Out 27 Timeout Preset
Default value:
0.00%
Setup:
1 setup
Data type:
Uint16
Set the output frequency transferred to the output terminal 27 when the terminal is configured as [48] Bus Ctrl Timeout in parameter
5-60 Terminal 27 Pulse Output Variable and a timeout is detected.
5-95 Pulse Out 29 Bus Control
Default value:
0.00%
Setup:
All setups
Data type:
Uint16
Set the output frequency transferred to the output terminal 29 when the terminal is configured as [45] Bus Controlled in parameter 5-63
Terminal 29 Pulse Output Variable.
5-96 Pulse Out 29 Timeout Preset
Default value:
0.00%
