Programming Guide | VLT® AutomationDrive FC 360
17-1* Inc.Enc.Interface
4.16.2
This parameter group is only valid when VLT
17-10 Signal Type
Default value:
[1] RS422 (5 V TTL)
Setup:
All setups
Data type:
Uint8
Select the incremental type (A/B channel) of the encoder in use. Find the information on the encoder datasheet.
Option
[0]
[1]
[2]
17-11 Resolution (PPR)
Default value:
1024
Setup:
All setups
Data type:
Uint16
Enter the resolution of the incremental track, which is the number of pulses or periods per revolution.
17-2* Abs. Enc. Interface
4.16.3
This parameter group is only valid when VLT
17-20 Protocol Selection
Default value:
[0] None
Setup:
All setups
Data type:
Uint8
Select the appropriate type of connected absolute encoder. If an incremental encoder is used, set parameter 17-10 Signal Type.
Option
[0]
[4]
266
| Danfoss A/S © 2024.01
NOTICE
®
Encoder Input MCB 102 is installed.
Parameter type:
Conversion index:
Change during operation:
Name
None
RS422 (5 V TTL)
Sinusoidal 1Vpp
Parameter type:
Conversion index:
Change during operation:
NOTICE
®
Encoder Input MCB 102 is installed.
Parameter type:
Conversion index:
Change during operation:
Name
None
SSI
Option
–
False
Range (10–16384)
0
False
Option
–
False
