Programming Guide | VLT® AutomationDrive FC 360
Option
[4]
[5]
Table 20: Table for Selection of Action when Selected Alarm Appears (Parameter 14-90 Fault Level)
Failure Alarm
Voltage 64
limit
Earth 14
(1)
fault
Overcurrent 13
Motor 30
phase U
missing
Motor 31
phase V
missing
Motor 32
phase W
missing
1) Only for drive of power size 30–75 kW (40–100 hp). If [0] Off is selected, the earth fault protection is disabled only for the earth fault which happens during running and
the short-circuit current to ground is lower than 200%.
D = Default setting
X = Possible selection
Disabling the ground fault may damage the drive and void the warranty.
Danfoss A/S © 2024.01
Name
Trip w. delayed reset
Fly start
Element in Off
parameter
14-90 Fault
Level
1490.3 X
1490.4 X
1490.7 –
1490.16 –
1490.16 –
1490.16 –
Warning Trip
D –
– –
– –
– X
– X
– X
NOTICE
Description
Alarm is configured into trip alarm,
which can be reset after a delay time.
For example, if alarm 13, Overcurrent is
configured to this option, it can be reset 3
minutes after the alarm. This option uses
index [7] to control the fault level of alarm
13, Overcurrent.
At start-up, the drive tries to catch a
spinning motor. If this option is selected,
parameter 1-73 Flying Start is forced
to [1] Enabled. This option uses index
[7] to control the fault level of alarm 13,
Overcurrent.
Trip lock Trip with
delayed
reset
– –
D –
D X
D –
D –
D –
AU275649936274en-001401 / 130R0507 |
Fly start
–
–
X
–
–
–
