Programming Guide | VLT® AutomationDrive FC 360
Setup:
All setups
Data type:
Uint8
Select the function of Terminal 42 as an analog current output.
Option
[0]
[100]
[101]
[102]
[103]
[104]
[105]
[106]
[107]
[111]
[113]
[139]
[143]
[254]
6-92 Terminal 42 Digital Output
Default value:
[0] No operation
Setup:
All setups
Data type:
Uint8
For the options of parameter 6-92 Terminal 42 Digital Output, see parameter 6-72 Terminal 45 Digital Output.
6-93 Terminal 42 Output Min Scale
Default value:
0.00%
Setup:
All setups
Data type:
Uint16
Scale for the minimum output (0 mA or 4 mA) of the analog signal at terminal 42. Set the value to be the percentage of the full range of
the variable selected in parameter 6-91 Terminal 42 Analog Output.
6-94 Terminal 42 Output Max Scale
Default value:
100.00%
156
| Danfoss A/S © 2024.01
Conversion index:
Change during operation:
Name
No operation
Output frequency
Reference
Process Feedback
Motor Current
Torque rel to limit
Torq relate to rated
Power
Speed
Speed Feedback
PID Clamped Output
Bus Control
Ext. CL 1
DC Link Voltage
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
–
True
Range
0–100 Hz
Min –Max
Ref Ref
Min –Max
FB FB
0–I
max
0–P
nom
0–100%
Option
–
True
Range (0.00–200.00%)
-2
True
Range (0.00–200.00%)
