Programming Guide | VLT® AutomationDrive FC 360
Recommended Initialization
3.1.6.2
1. Select parameter 14-22 Operation Mode and press [OK].
2. Select [2] Initialization and press [OK].
3.
Remove power to the unit and wait until the display turns off.
4.
Apply power to the unit.

Default parameter settings are restored during start-up. This may take slightly longer than normal.
5.
Alarm 80, Drive initialized to default value is shown.
6. Press [Reset] to return to operating mode.
Manual Initialization
3.1.6.3
1.
Remove power to the unit and wait until the display turns off.
2.
Press and hold [Status], [Main Menu], and [OK] at the same time on the GLCP, or press [Menu] and [OK] at the same time on the
NLCP while applying power to the unit (approximately 5 s or until a click is heard and the fan starts).

Factory default parameter settings are restored during start-up. This may take slightly longer than normal.
Basic Programming
3.2
Asynchronous Motor Setup
3.2.1
Enter the following motor data in the listed order. Find the information on the motor nameplate.
1.
Parameter 1-20 Motor Power.
2.
Parameter 1-22 Motor Voltage.
3.
Parameter 1-23 Motor Frequency.
4.
Parameter 1-24 Motor Current.
5.
Parameter 1-25 Motor Nominal Speed.
For optimum performance in VVC+ mode, extra motor data is required to set up the following parameters.
1.
Parameter 1-30 Stator Resistance (Rs).
2.
Parameter 1-31 Rotor Resistance (Rr).
3.
Parameter 1-33 Stator Leakage Reactance (X1).
4.
Parameter 1-35 Main Reactance (Xh).
The data is found in the motor datasheet (this data is typically not available on the motor nameplate). Run a complete AMA using
parameter 1-29 Automatic Motor Adaption (AMA)[1] Enable Complete AMA or enter the parameters manually.
Application-specific adjustment when running VVC+
VVC+ is the most robust control mode. In most situations, it provides optimum performance without further adjustments. Run a
complete AMA for best performance.
PM Motor Set-up in VVC+
3.2.2
Initial Programming Steps
3.2.2.1
1.
Set parameter 1-10 Motor Construction to the following options to activate PM motor operation:
[1] PM, non salient SPM
¢
