Programming Guide | VLT® AutomationDrive FC 360
Set the nominal back EMF for the motor when running at 1000 RPM. Back EMF is the voltage generated by a PM motor when no drive
is connected and the shaft is turned externally. Back EMF is normally specified for nominal motor speed or for 1000 RPM measured
between 2 lines. If the value is not available for a motor speed of 1000 RPM, calculate the correct value as follows: If back EMF is, for
example, 320 V at 1800 RPM, it can be calculated at 1000 RPM:
Example:
Back EMF 320 V at 1800 RPM. Back EMF = (Voltage/RPM)*1000 = (320/1800)*1000 = 178.
This parameter is only active when parameter 1-10 Motor Construction is set to options that enable PM (permanent magnet) motors.
When using PM motors, it is recommended to use brake resistors.
1-41 Motor Angle Offset
Default value:
0
Setup:
All setups
Data type:
Int16
Enter the offset angle between PM motor and index position of the attached encoder.
When to find the offset angle: after the drive start-up, applying DC hold, and entering the value of parameter 16-20 Motor Angle.
This parameter is only active when parameter 1-10 Motor Construction is set to [1] PM motor.
1-42 Motor Cable Length
Default value:
Size related
Setup:
All setups
Data type:
Uint8
Set the motor cable length in meters.
1-43 Motor Cable Length Feet
Default value:
Size related
Setup:
All setups
Data type:
Uint16
Set the motor cable length. The length unit is foot.
1-44 d-axis Inductance Sat. (LdSat)
Default value:
Size related
Setup:
All setups
Data type:
Int32
Danfoss A/S © 2024.01
NOTICE
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Range (-32768–32767)
0
True
Range (0–100 m)
0
False
Range (0–328 ft)
0
False
Range (0.001–65535.000 mH)
-3
False
