Danfoss VLT AutomationDrive FC 360 Programming Manual page 12

Programming Guide | VLT® AutomationDrive FC 360
Electrical Wiring - Control Cables
1.5
Overview
1.5.1
RFI
91 (L1)
3 phase
92 (L2)
power
93 (L3)
input
95
50 (+ 10 V OUT)
+ 10 V DC
0-10 V DC
53 (A IN)
0/4-20 mA
0-10 V DC
54 (A IN)
0/4-20 mA
55 (COM A IN/OUT)
42 (A OUT)
Analog
output
0/4-20 mA
45 (A OUT)
12 (+ 24 V OUT)
18 (D IN)
19 (D IN)
20 (COM D IN)
27 (D IN/OUT)
29 (D IN/OUT)
31 (D IN)
32 (D IN)
33 (D IN)
Figure 1: Wiring Diagram
A = Analog, D = Digital
10
| Danfoss A/S © 2024.01
3)
PE
Switch mode
power supply
10 V DC
15 mA
+
P 5-00
24 V (NPN)
0 V (PNP)
24 V (NPN)
0 V (PNP)
24 V (NPN)
0 V (PNP)
24 V
0 V
24 V (NPN)
0 V (PNP)
24 V
0 V
24 V (NPN)
0 V (PNP)
24 V (NPN)
0 V (PNP)
24 V (NPN)
0 V (PNP)
1)
24 V DC
100 mA
- + -
4)
ON= Terminated
OFF= Open
5V
S801
RS485
(N RS485)
Interface
(P RS485)
0 V
(COM RS485)
(U) 96
(V) 97
(W) 98
(PE) 99
(-UDC) 88 6)
(+ UDC) 89 6)
Brake
resistor
(BR) 81 5)
Relay 1
03
250 V AC, 3 A
02
01
Relay 2 2)
06
250 V AC, 3 A
05
04
0V
RS485
69
68
61
(PNP) = Source
(NPN) = Sink
AU275649936274en-001401 / 130R0507
Motor
