Programming Guide | VLT® AutomationDrive FC 360
6-73 Terminal 45 Output Min Scale
Default value:
0.00%
Setup:
All setups
Data type:
Uint16
Scale for the minimum output (0 or 4 mA) of the analog signal at terminal 45. Set the value to be the percentage of the full range of the
variable selected in parameter 6-71 Terminal 45 Analog Output.
6-74 Terminal 45 Output Max Scale
Default value:
100.00%
Setup:
All setups
Data type:
Uint16
Scale for the maximum output (20 mA) of the analog signal at terminal 45. Set the value to be the percentage of the full range of the
variable selected in parameter 6-71 Terminal 45 Analog Output.
6-76 Terminal 45 Output Bus Control
Default value:
0
Setup:
All setups
Data type:
Uint16
Hold the level of analog output if controlled by bus.
6-9* Analog/Digital Output 42
4.7.6
Parameters for configuring the limits for analog/digital output terminal 42. Analog outputs are current outputs: 0/4–20 mA. Resolution
on analog outputs is 12 bit. Analog output terminals can also be set up as digital output.
6-90 Terminal 42 Mode
Default value:
[0] 0-20 mA
Setup:
All setups
Data type:
Uint8
Set terminal 42 to act as analog output or as digital output.
Option
[0]
[1]
[2]
6-91 Terminal 42 Analog Output
Default value:
[0] No operation
Danfoss A/S © 2024.01
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Name
0-20 mA
4-20 mA
Digital Output
Parameter type:
AU275649936274en-001401 / 130R0507 |
Range (0.00–200.00%)
-2
True
Range (0.00–200.00%)
-2
True
Range (0–16384)
0
True
Option
–
True
Option
155
