Programming Guide | VLT® AutomationDrive FC 360
Table 26: Description of Alarm Word (continued)
Bit Hex Dec
6 00000040 64
7 00000080 128
8 00000100 256
9 00000200 512
10 00000400 1024
11 00000800 2048
12 00001000 4096
13 00002000 8192
14 00004000 16384
15 00008000 32768
16 00010000 65536
17 00020000 131072
18 00040000 262144
19 00080000 524288
20 00100000 1048576
21 00200000 2097152
22 00400000 4194304
23 00800000 8388608
24 01000000 16777216
25 02000000 33554432
26 04000000 67108864
27 08000000 134217728
28 10000000 268435456
29 20000000 536870912
30 40000000 1073741824
31 80000000 2147483648
310
| Danfoss A/S © 2024.01
Alarm word
Parameter 16-90 Alarm Word
Torque limit (A12)
Motor th over (A11)
Motor ETR over (A10)
Inverter overld. (A9)
DC under volt (A8)
DC over volt (A7)
Short circuit (A16)
–
Mains ph. loss (A4)
AMA not OK
Live zero error (A2)
Internal fault (A38)
Brake overload (A26)
U phase loss (A30)
V phase loss (A31)
W phase loss (A32)
Fieldbus fault (A34)
24 V supply low (A47)
Mains failure (A36)
–
Brake resistor (A25)
Brake IGBT (A27)
Option change (A67)
Drive initialized (A80)
Safe stop (A68)
Mech. brake low (A63)
Alarm word 2
Parameter 16-91 Alarm Word
2
–
–
Broken Belt
–
Start failed
Speed limit
External interlock
–
–
–
Earth fault DESAT
–
Fans error
–
Option Detection
Option Fault
Locked rotor
Position control fault
–
Current limit (A59)
–
–
Feedback Fault
Encoder loss (A90)
–
–
AU275649936274en-001401 / 130R0507
Alarm word 3
Parameter 16-97 Alarm Word
3
Profibus converter invalid
User Alert Alarm
No Motor
Output Freq Limit
Hoist Mech Brake
Temp Input Error
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
