32-Bit Arm ® Cortex ® -M0+ MCU
HT32F52220/HT32F52230
Bits Field
[18:16] MMSEL
Rev. 1.10
Descriptions
Master Mode Selection
Master mode selection is used to select the MTO signal source which is used to
synchronize the other slave timer.
MMSEL [2:0] Mode
000 Reset Mode
001 Enable Mode
010 Update Mode
Capture/Compare
011
Mode
100 Compare Mode 0
101 Compare Mode 1
110 Compare Mode 2
111 Compare Mode 3
204 of 366
Descriptions
The MTO in the Reset mode is an output derived
from one of the following cases:
1. Software setting UEVG bit
2. The STI trigger input signal which will be
output on the MTO signal line when the Timer
is used in the slave Restart mode
The Counter Enable signal is used as the trigger
output.
The update event is used as the trigger output
according to one of the following cases when the
UEVDIS bit is cleared to 0:
1. Counter overflow / underflow
2. Software setting UEVG
3. Slave trigger input when used in slave restart
mode
When a Channel 0 capture or compare match
event occurs, it will generate a positive pulse
used as the master trigger output.
The Channel 0 Output reference signal named
CH0OREF is used as the trigger output.
The Channel 1 Output reference signal named
CH1OREF is used as the trigger output.
The Channel 2 Output reference signal named
CH2OREF is used as the trigger output.
The Channel 3 Output reference signal named
CH3OREF is used as the trigger output.
