[0] TXR
USART Interrupt Enable Register – USRIER
This register is used to enable the related USART interrupt function. The USART module generates interrupts to
the controller when the corresponding events occur and the corresponding interrupt enable bits are set.
Offset: 0x00C
Reset value: 0x0000_0000
31
Type/Reset
23
Type/Reset
15
Type/Reset
7
RSADDIE
Type/Reset RW 0 RW
Bits Field
[9] CTSIE
[8] RXTOIE
[7] RSADDIE
[6] BIE
Rev. 1.10
Descriptions
TX FIFO Reset
Setting this bit will generate a reset pulse to reset TX FIFO which will empty the TX
FIFO. i.e., the TX FIFO pointer will be reset to 0, after a reset signal. This bit returns
to 0 automatically after the reset pulse is generated.
30 29 28
22 21 20
14 13 12
Reserved
6 5 4
BIE FEIE PEIE
0 RW 0 RW
Descriptions
CTS Clear-To-Send Interrupt Enable
0: Disable interrupt
1: Enable interrupt
An interrupt will be generated when the CTSC bit is set in the USRSIFR register.
Receive FIFO Time-Out Interrupt Enable
0: Disable interrupt
1: Enable interrupt
Receive FIFO Time-Out Interrupt means that receive FIFO is not empty and no
activities have occurred in the receive FIFO during the time-out duration specified
by the RXTOC field.
RS485 Address Detection Interrupt Enable
0: Disable interrupt
1: Enable interrupt
An interrupt will be generated when the RSADD bit is set in the USRSIFR register.
Break Interrupt Enable
0: Disable interrupt
1: Enable interrupt
An interrupt will be generated when the BII bit is set in the USRSIFR register.
345 of 366
27 26
Reserved
19 18
Reserved
11 10
RW
3 2
OEIE TXCIE
0 RW 0 RW 0 RW
25 24
17 16
9 8
CTSIE RXTOIE
0 RW 0
1 0
TXDEIE RXDRIE
0 RW 0
