Table 20. Afio, Gpio And Io Pad Control Signal True Table; Figure 19. Afio/Gpio Control Signal - Holtek HT32F52220 User Manual

32-Bit Arm ® Cortex ® -M0+ MCU
HT32F52220/HT32F52230
PxCFGn
Input
DMUX
Output
MUX
IP
AFIO
OEN
IP
Control
AFIO
PxDOUTn
PxRSTn
PxSETn
GPIO

Figure 19. AFIO/GPIO Control Signal

PxDINn/PxDOUTn (x=A ~ B): Data Input/Data Output
PxDIRn (x=A ~ B): Direction
PxDVn (x=A ~ B): Output Drive
PxPDn/PxPUn (x=A ~ B): Pull Down/Up

Table 20. AFIO, GPIO and IO Pad Control Signal True Table

Type
GPIO Input (Note)
GPIO Output
(Note)
AFIO Input
AFIO Output
ADC Input
OSC Output
Note: The signals, IEN and OEN, for I/O pads are derived from the GPIO register bits PxINENn and
PxDIRn respectively when the associated pin is configured in the GPIO input/output mode.
