32-Bit Arm
®
Cortex
®
-M0+ MCU
HT32F52220/HT32F52230
Bits
Field
[1]
CH1CCIF
[0]
CH0CCIF
Timer Counter Register – CNTR
This register stores the timer counter value.
Offset:
0x080
Reset value: 0x0000_0000
31
Type/Reset
23
Type/Reset
15
Type/Reset
RW
0 RW
7
Type/Reset
RW
0 RW
Bits
Field
[15:0]
CNTV
Rev. 1.10
Descriptions
Channel 1 Capture/Compare Interrupt Flag
- Channel 1 is configured as an output:
0: No match event occurs
1: The contents of the counter CNTR have matched the contents of the CH1CCR
register
This flag is set by hardware when the counter value matches the CH1CCR value
except in the center-aligned mode. It is cleared by software.
- Channel 1 is configured as an input:
0: No input capture occurs
1: Input capture occurs
This bit is set by hardware on a capture event. It is cleared by software or by
reading the CH1CCR register.
Channel 0 Capture/Compare Interrupt Flag
- Channel 0 is configured as an output:
0: No match event occurs
1: The contents of the counter CNTR have matched the content of the CH0CCR
register
This flag is set by hardware when the counter value matches the CH0CCR value
except in the center-aligned mode. It is cleared by software.
- Channel 0 is configured as an input:
0: No input capture occurs
1: Input capture occurs
This bit is set by hardware on a capture event. It is cleared by software or by
reading the CH0CCR register.
30
29
28
22
21
20
14
13
12
0 RW
0 RW
6
5
4
0 RW
0 RW
Descriptions
Counter Value.
227 of 366
27
26
Reserved
19
18
Reserved
11
10
CNTV
0 RW
0 RW
0 RW
3
2
CNTV
0 RW
0 RW
0 RW
25
24
17
16
9
8
0 RW
0
1
0
0 RW
0
November 09, 2018
