32-Bit Arm ® Cortex ® -M0+ MCU
HT32F52220/HT32F52230
BFTM Counter Register – BFTMCNTR
This register specifies the BFTM counter value.
Offset: 0x008
Reset value: 0x0000_0000
31
Type/Reset RW 0 RW
23
Type/Reset RW 0 RW
15
Type/Reset RW 0 RW
7
Type/Reset RW 0 RW
Bits Field
[31:0] CNT
BFTM Compare Value Register – BFTMCMPR
The register specifies the BFTM compare value.
Offset: 0x00C
Reset value: 0xFFFF_FFFF
31
Type/Reset RW 1 RW
23
Type/Reset RW 1 RW
15
Type/Reset RW 1 RW
7
Type/Reset RW 1 RW
Bits Field
[31:0] CMP
Rev. 1.10
30 29 28
0 RW 0 RW
22 21 20
0 RW 0 RW
14 13 12
0 RW 0 RW
6 5 4
0 RW 0 RW
Descriptions
BFTM Counter Value
A 32-bit BFTM counter value is stored in this field which can be read or written on-
the-fly.
30 29 28
1 RW 1 RW
22 21 20
1 RW 1 RW
14 13 12
1 RW 1 RW
6 5 4
1 RW 1 RW
Descriptions
BFTM Compare Value
This register specifies a 32-bit BFTM compare value which is used for comparison
with the BFTM counter value.
241 of 366
27 26
CNT
0 RW 0 RW 0 RW
19 18
CNT
0 RW 0 RW 0 RW
11 10
CNT
0 RW 0 RW 0 RW
3 2
CNT
0 RW 0 RW 0 RW
27 26
CMP
1 RW 1 RW 1 RW
19 18
CMP
1 RW 1 RW 1 RW
11 10
CMP
1 RW 1 RW 1 RW
3 2
CMP
1 RW 1 RW 1 RW
25 24
0 RW 0
17 16
0 RW 0
9 8
0 RW 0
1 0
0 RW 0
25 24
1 RW 1
17 16
1 RW 1
9 8
1 RW 1
1 0
1 RW 1
