32-Bit Arm ® Cortex ® -M0+ MCU
HT32F52220/HT32F52230
ADC Conversion List Register 1 – ADCLST1
This register specifies the conversion sequence order No.4 ~ No.7 of the ADC.
Offset: 0x008
Reset value: 0x0000_0000
31
Reserved
Type/Reset
23
Reserved
Type/Reset
15
Reserved
Type/Reset
7
Reserved
Type/Reset
Bits Field
[28:24] ADSEQ7
[20:16] ADSEQ6
[12:8] ADSEQ5
[4:0] ADSEQ4
Rev. 1.10
30 29 28
RW
22 21 20
RW
14 13 12
RW
6 5 4
RW
Descriptions
ADC Conversion Sequence Select 7
Select the ADC input channel for the 7
0x0: ADC_IN0
0x1: ADC_IN1
0x2: ADC_IN2
0x3: ADC_IN3
0x4: ADC_IN4
0x5: ADC_IN5
0x6: ADC_IN6
0x7: ADC_IN7
0x8 ~ 0xF: Reserved
0x10: Analog ground, AVSS (V
0x11: Analog power, AVDD (V
0x12 ~ 0x1F: Invalid setting. These values must not be selected as it may cause
the ADC abnormal operations.
ADC Conversion Sequence Select 6
ADC Conversion Sequence Select 5
ADC Conversion Sequence Select 4
164 of 366
27 26
ADSEQ7
0 RW 0 RW 0 RW
19 18
ADSEQ6
0 RW 0 RW 0 RW
11 10
ADSEQ5
0 RW 0 RW 0 RW
3 2
ADSEQ4
0 RW 0 RW 0 RW
th ADC conversion sequence.
)
REF-
)
REF+
25 24
0 RW 0
17 16
0 RW 0
9 8
0 RW 0
1 0
0 RW 0
November 09, 2018
