32-Bit Arm ® Cortex ® -M0+ MCU
HT32F52220/HT32F52230
Bits Field
[1] ADWUE
[0] ADWLE
ADC Watchdog Threshold Register – ADCTR
This register specifies the upper and lower threshold of the ADC watchdog function.
Offset: 0x07C
Reset value: 0x0000_0000
31
Type/Reset
23
Type/Reset RW 0 RW
15
Type/Reset
7
Type/Reset RW 0 RW
Bits Field
[27:16] ADUT
[11:0] ADLT
Rev. 1.10
Descriptions
ADC Watchdog Upper Threshold Enable Bit
0: Disable upper threshold monitor function
1: Enable upper threshold monitor function
ADC Watchdog Lower Threshold Enable Bit
0: Disable lower threshold monitor function
1: Enable lower threshold monitor function
30 29 28
Reserved
22 21 20
0 RW 0 RW
14 13 12
Reserved
6 5 4
0 RW 0 RW
Descriptions
ADC Watchdog Upper Threshold Value
Specify the upper threshold for the ADC watchdog monitor function.
ADC Watchdog Lower Threshold Value
Specify the lower threshold for the ADC watchdog monitor function.
170 of 366
27 26
RW 0 RW 0 RW
19 18
ADUT
0 RW 0 RW 0 RW
11 10
RW 0 RW 0 RW
3 2
ADLT
0 RW 0 RW 0 RW
25 24
ADUT
0 RW 0
17 16
0 RW 0
9 8
ADLT
0 RW 0
1 0
0 RW 0
November 09, 2018
