32-Bit Arm
®
Cortex
®
-M0+ MCU
HT32F52220/HT32F52230
USART Divider Latch Register – USRDLR
The register is used to determine the USART clock divided ratio to generate the appropriate baud rate.
Offset:
0x024
Reset value: 0x0000_0010
31
Type/Reset
23
Type/Reset
15
Type/Reset
RW
0 RW
7
Type/Reset
RW
0 RW
Bits
Field
[15:0]
BRD
Rev. 1.10
30
29
28
22
21
20
14
13
12
0 RW
0 RW
6
5
4
0 RW
0 RW
Descriptions
Baud Rate Divider
The 16 bits define the USART clock divider ratio.
Baud Rate = CK_USART / BRD
Where the CK_USART clock is the clock connected to the USART module.
BRD = 16 ~ 65535 for asynchronous mode
BRD = 8 ~ 65535 for synchronous mode
352 of 366
27
26
Reserved
19
18
Reserved
11
10
BRD
0 RW
0 RW
0 RW
3
2
BRD
1 RW
0 RW
0 RW
25
24
17
16
9
8
0 RW
0
1
0
0 RW
0
November 09, 2018
