Inter-Integrated Circuit (I

Introduction

The I 2 C Module is an internal circuit allowing communication with an external I
is an industry standard two line serial interface used for connection to external hardware. These
two serial lines are known as a serial data line, SDA, and a serial clock line, SCL. The I
provides three data transfer rates: (1) 100 kHz in the Standard mode, (2) 400 kHz in the Fast mode
and (3) 1MHz in the Fast-mode plus. The SCL period generation register is used to setup different
kinds of duty cycle implementation for the SCL pulse.
The SDA line which is connected to the whole I
master and slave devices used for the transmission and reception of data. The I
an arbitration detection function to prevent the situation where more than one master attempts to
transmit data on the I
APB Bus
Figure 82. I 2 C Module Block Diagram
Rev. 1.10
2 C bus at the same time.
Control Register
Interrupts
SCL High/Low
SCL
period
Generator
Generation
Address/Data
Target Register
Data Shift Register
Data Register
Address Address
Register
Comparator
Status
Arbitration
Register
Bus Status
