Polycom RMX 1500 Administrator's Manual page 821

Table I-1 lists components and versions of the RMX and Cisco Telepresence Systems (CTS)
Integration Solution Architecture.
Table I-1
Component
CISCO Equipment
CUCM
IOS
Endpoints (CTS)
Polycom Equipment
DMA 7000
RMX
MLA
Polycom, Inc.
Solution Architecture Components
Version
8.5
15.x
1.7
3.0
7.6
3.0.3
Appendix I-RMX and Cisco Telepresence Systems (CTS) Integration
Description
Cisco Unified Communication Manager:
CUCM must be configured to:
• Route calls to DMA (if present).
•
Route all H.323 calls to the gatekeeper, which can
be either CMA or IOS.
Cisco Internetwork Operating System - Gatekeeper
Telephony, desktop and room systems.
•
CTS endpoints must register to CUCM.
Polycom Distributed Media Application
•
DMA is an optional component but is essential if
Content sharing is to be enabled.
•
All SIP endpoints register to DMA as a SIP Proxy.
•
DMA should be configured to route SIP calls (with
CTS destination) to CUCM. If DMA is not present in
the solution architecture, SIP endpoints must
register to CUCM as gatekeeper.
• DMA must be configured with a VMR (Virtual
Meeting Room). Incoming calls are then routed to
the RMX.
MCU:
• Functions as the network bridge for multipoint calls
between H.323, SIP and TIP endpoints.
• The RMX can be interfaced to CUCM using a SIP
trunk, enabling CTS to join multipoint calls on RMX.
Signaling goes through the CUCM while the media
in TIP format goes directly between the CTS and
RMX.
• The RMX must be configured to route outbound SIP
calls to DMA.
•
The H.323 Network Service of the RMX should
register it's dial prefix with the CMA gatekeeper.
•
When DMA is not used an Ad-hoc Entry Queue,
designated as Transit Entry Queue, must be pre-
defined on the RMX.
Multipoint Layout Application
Required for managing multi-screen endpoint layouts
for Cisco CTS 3XXX, Polycom TPX, RPX or OTX
systems.
I-3
