Polycom RMX 1500 Administrator's Manual page 161

Table 3-4
Dialing
Direction
RMX
Level 1
to
RMX
Level 2
RMX
Level 2
to
RMX
Level 1
•
•
Creating a Cascade Enabled Entry Queue
Cascade-enabled Entry Queues do not play IVR prompts and video slide displays associated
with standard Entry Queues.
Depending on the dialing direction, a cascade-enabled Entry Queue is defined either on the
MCU on level 1 or on level 2. (See "Dialing Direction").
The definition of the Entry Queue as Master or Slave is done accordingly.
To define a Cascade-Enabled Entry Queue:
1
2
Polycom, Inc.
Set up Procedures according to the Dialing Direction
RMX Level 1
Define the conference line rate and if
required to HD Video Switching to be
the same as the one set on the
RMX Level 2.
Define the dial-out participant
(Cascaded Link) to the conference
running on the RMX on Level 2, setting
it as Master.
Define the cascade-enabled Entry
Queue, setting it as Master.
Define the conference line rate and
Video Session Mode to be the same as
the one set on RMX Level 2.
When cascading between a DST MCS 4000 on level 3 and the RMX on level 2, the RMX must
dial out to the MCS 4000 to establish the Master-Slave relationship (the RMX is the Master).
If the RMX on level 2 is being dialed from both Level 1 and Level 3 and it is acting as both Slave
to level 1 and Master to Level 3, two Cascade-enabled Entry Queues must be defined: one
defined as Slave (for dial in from conferences running on MCU Level 1) and the other defined as
Master (for dial in from conferences running on MCU Level 3).
In the RMX Management pane, click Entry Queues.
The Entry Queues list pane is displayed.
Click the New Entry Queue (
RMX Level 2
Define the cascade-enabled Entry
Queue, defining it as Slave.
Define the conference line rate and if
required to HD Video Switching to be
the same as the one set on the
RMX Level 1.
Define the conference line rate and
Video Session Mode to be the same as
the one set on RMX Level 1.
Define the dial-out participant
(Cascaded Link) to the conference
running on the RMX on Level 2, setting
it as Slave.
) button.
Chapter 3-Cascading Conferences
3-31
